AMAT Applied Materials 0100-90978继电器板
1.产 品 资 料 介 绍：
关键规格
功能特点
典型应用
AMAT Applied Materials 0100-90978继电器板 英文资料：
The AMAT Applied Materials 0100-90978 relay board is an 8-channel solid-state/electromagnetic hybrid control board, suitable for signal isolation and power switching of devices such as semiconductors and flat panel displays.
Key specifications
Project specification remarks
Relay type: 4-channel SSR (solid-state)+4-channel EMR (electromagnetic) SSR high-speed contactless, EMR high load
Contact capacity SSR: 240VAC/6A; EMR: 250VAC/10A typical value
Coil voltage 24 VDC compatible with PLC/controller
Isolation method: photoelectric isolation+electrical isolation, strong anti-interference ability
Control signal 5-24 VDC logic input compatible with TTL/CMOS
Interface form: pluggable terminal block (Phoenix) for easy maintenance
Installation method: Panel type/rail type adaptive equipment cabinet
Size 100 × 160 × 40 mm (approximately) Compact design
Protection level IP20 dustproof and splash proof
Features
Hybrid design: Combining the high-frequency response of SSR with the high load capacity of EMR, suitable for diverse load requirements.
Electrical isolation: Each signal is completely isolated from the power supply, reducing the risk of interference and misoperation.
Status indication: Each channel is equipped with LED indicator lights for real-time monitoring of work status.
Hot swappable support: Relay modules can be replaced while live, improving maintenance efficiency.
Compact structure: 1/2 rack size, space saving, suitable for devices with limited space.
Typical Applications
Gas valve control for vacuum coating machines, CVD, PVD equipment
Switching between RF source and matching device of plasma etching machine
Electromagnetic valve and contactor drive in industrial automation
Signal path switching of testing equipment
AMAT Applied Materials 0100-90978继电器板 产品展示
