AMAT Applied Materials 0100-00206 PCB组件
1.产 品 资 料 介 绍：
AMAT Applied Materials 0100-00206 PCB 组件
核心功能
技术特点
典型应用
AMAT Applied Materials 0100-00206 PCB组件 英文资料：
AMAT Applied Materials 0100-00206 PCB Components
AMAT 0100-00206 is a multi-layer printed circuit board component designed specifically for semiconductor manufacturing equipment, integrating signal processing, power distribution, and interface conversion functions as the core connection and control hub between device subsystems.
core functionality
Centralized signal processing: integrating operational amplifiers, filters, and logic circuits to achieve conditioning and conversion of multi-channel analog/digital signals
Power Management: Provides multiple isolated power outputs (5V, 12V, 24V) to power surrounding sensors and actuators
Interface conversion: realize the conversion and adaptation of different level signals (TTL/CMOS/RS-485)
System interconnection: As an intermediate adapter board, it connects the main controller with various functional modules
Status monitoring: Integrated fault detection circuit, real-time monitoring of power and signal status
Technical Features
Project specifications
6-8 layer structure high-density PCB design
Working temperature -10 ℃~60 ℃
Supply voltage 24VDC (± 10%)
Signal channels 16-32 analog inputs/outputs
32-64 channels of digital input/output
Isolation level: 2.5kVrms between signals, 5kVrms between power supply and signals
Size specification standard 160 × 100mm (customizable)
Connector type: high-density needle socket combined with Phoenix terminal
Protection design with moisture-proof and anti-corrosion coating treatment
Typical Applications
Sensor signal acquisition and processing of semiconductor etching equipment
Distribution of actuator control signals for sedimentation equipment
Status monitoring and control signal switching of vacuum system
Coordination and control of auxiliary equipment around the process chamber
