AMAT Applied Materials 0660-00144印刷电路板

AMAT Applied Materials  0660-00144印刷电路板

1.产 品 资 料 介 绍：

核心规格

功能特点

• 混合信号处理：可同时传输数字、模拟、电源信号，支持复杂系统拓扑。
• 模块化设计：通道可灵活配置，便于扩展与维护。
• 状态监测：每路配备 LED 指示灯，实时显示工作状态。
• 热插拔支持：带电更换模块，减少停机时间。
• 低噪声设计：多层 PCB + 屏蔽设计，抑制串扰与噪声干扰。

典型应用

• 离子注入机、刻蚀机、PVD/CVD 等设备的控制信号分配
• 工业自动化中的传感器 / 执行器信号转接
• 测试系统中的多路信号同步传输

AMAT Applied Materials 0660-00144印刷电路板 英文资料：

AMAT Applied Materials 0660-00144 printed circuit board is an E300 series high-density multi-layer signal/power distribution board, mainly used for isolation and distribution of multi-channel control, drive, and power signals in semiconductor equipment. Version Rev. 04, compatible with multiple generation platforms.

Core specifications

Project specification remarks

Application Series E300 High Density Multi Channel Distribution Board

Version number Rev. 04 Hardware iteration marker

Functional signals/power distribution and isolation control, drive, power and other signals

16 channels (customizable), typically with 16 outputs

Interface type: high-density needle socket, connector (Phoenix/TE) compatible with device backplane/daughter board

Working voltage 5-24 VDC (multi rail) supports mixed voltage distribution

Isolation method: photoelectric isolation+electrical isolation. Each circuit is independent and has strong anti-interference ability

Installation method: panel type/rail type standard cabinet adaptation

Size 160 × 100 × 40 mm (approximately) Compact design

Protection level IP20 dustproof and splash proof

Features

Mixed signal processing: capable of simultaneously transmitting digital, analog, and power signals, supporting complex system topologies.

Modular design: Channels can be flexibly configured for easy expansion and maintenance.

Status monitoring: Each channel is equipped with LED indicator lights to display the working status in real-time.

Hot swappable support: ｒｅｐｌａｃｅ modules with power on to reduce downtime.

Low noise design: multi-layer PCB+shielding design to suppress crosstalk and noise interference.

Typical Applications

Control signal distribution for ion implantation machines, etching machines, PVD/CVD and other equipment

Sensor/actuator signal conversion in industrial automation

Synchronized transmission of multiple signals in the testing system

AMAT Applied Materials  0660-00144印刷电路板 产品展示

 产品视频
