AMAT Applied Materials 0100-02715背板
1.产 品 资 料 介 绍：
核心规格
功能特点
典型应用
安装与维护建议
AMAT Applied Materials 0100-02715背板 英文资料：
AMAT Applied Materials 0100-02715 is a high-density multi-layer passive backplane that serves as the signal and power backbone connection between subsystems within semiconductor manufacturing equipment, providing a high-speed, low loss, and high reliability interconnect platform.
Core specifications
Project specifications
Board structure 8-16 layer high-speed PCB (optional higher layers)
Low loss board material system (such as Isola 370HR, Rogers 4350B), high Tg (170 ℃+)
Size standard 19 inch rack adaptation, or customized according to equipment
Connector type: high-density European style needle socket, crimping connector, supporting hot plugging
Signal characteristics support high-speed differential signals (such as LVDS, PCIe) and full line impedance control
Power distribution multi rail isolated power plane (5V, 12V, 24V), copper plane carries high current
Working temperature -10 ℃~60 ℃
Isolation and protection: The signal and power supply should be isolated by ≥ 5kVrms, and the surface should be coated with a moisture-proof and corrosion-resistant coating
Backboard type: Passive backplane, without active signal processing circuit
Features
Modular slot design: supports parallel access of multiple daughter boards, enabling flexible system expansion
Low noise design: multi-layer planar+shielding layer structure, suppressing crosstalk and EMI interference
Hot swappable capability: ｒｅｐｌａｃｅ daughter board with power on, reduce downtime
High mechanical strength: thick copper layer+high-strength substrate, capable of withstanding multiple insertions and removals without deformation
Status monitoring: equipped with power and signal indicator lights for quick fault location
Typical Applications
Control and Data Transmission of Semiconductor Etching Machines and PVD/CVD Deposition Equipment
Signal distribution and synchronization control of ion implantation machine
Interconnection of vacuum system, process chamber and robot control unit
Installation and maintenance recommendations
install
Installed in a well shielded rack away from strong electromagnetic interference sources
Ensure that the backplane and daughter board connectors are fully aligned and locked
wiring
Strictly distinguish signals and power supplies according to pin definitions to avoid misconnection
Suggest using shielded wires and single point grounding to reduce interference
maintenance
Check the tightness of the connector every 6-12 months to prevent oxidation and loosening
Regularly clean dust to ensure good heat dissipation
When replacing the daughter board, follow the anti-static regulations to prevent static electricity from damaging the back panel
AMAT Applied Materials 0100-02715背板 产品展示
