AMAT Applied Materials 0010-09181直流电源器
1.产 品 资 料 介 绍：
核心规格
功能特点
典型应用
AMAT Applied Materials 0010-09181直流电源器 英文资料：
AMAT Applied Materials 0010-09181 is an industrial grade DC power supply device mainly used for supplying power to control and drive circuits of semiconductor equipment. It adopts a multi group isolated output design and can simultaneously provide stable DC voltages such as+48V, ± 14V,+24V, etc., meeting the multi voltage requirements of equipment.
Core specifications
Project specification remarks
The input voltage depends on the model (commonly 95-264 VAC or 340-480 VAC) and is compatible with the global power grid
Output voltage/current+48 V/± 14 V/+24 V; total current of about 3-5 A (distributed according to load), multiple sets of isolated outputs
Efficiency ≥ 85% (full load) typical value
Isolation voltage input/output 1500 VAC in accordance with IEC 60950-1
Protection function: automatic recovery or latch for overvoltage, undervoltage, overcurrent, short circuit, overheating
Working temperature -20 ℃~+60 ℃ (some require derating) Natural air cooling
The size depends on the packaging (commonly 1U/2U chassis or PCB plug-in), standard industrial packaging
Certified CE, UL, FCC, RoHS, some models are equipped with SEMI S2
Interface 2-pin/4-pin power input; DB9/RS-485/Ethernet (some with monitoring) for remote monitoring convenience
Features
Multiple independent outputs: can simultaneously supply power to different circuit modules, isolate each other, and reduce interference.
High reliability design: Suitable for industrial environments and equipped with multiple protection mechanisms.
Wide voltage adaptation: can be directly connected to 110V or 220V power grids.
Compact structure: saves installation space.
Typical Applications
Power supply for semiconductor equipment control system
Industrial automation PLC, HMI, sensor power supply
Distributed power supply for network communication equipment
Power supply for precision testing instruments
AMAT Applied Materials 0010-09181直流电源器 产品展示
