AMAT Applied Materials 0100-09307继电器模块

AMAT Applied Materials 0100-09307继电器模块

1.产 品 资 料 介 绍：

关键参数

功能特点

• 隔离保护：光耦隔离控制电路与负载电路，防止干扰与浪涌。
• 多协议通信：支持 RS-232/485/422，方便接入不同控制系统。
• 直观状态指示：每路配 LED 指示灯，实时显示工作状态。
• 地址 / 波特率可调：通过拨码开关设置地址（0–255）和波特率（2400–19200bps），支持多模块组网。
• 低功耗设计：静态功耗 < 5W，适合长时间稳定运行。

典型应用

• 半导体设备气体阀门、真空泵、加热元件控制
• 光伏制造中的电源切换与安全联锁
• 自动化生产线的 I/O 扩展与远程控制
• 工业环境中的多路开关量控制

AMAT Applied Materials 0100-09307继电器模块 英文资料：

AMAT 0100-09307 is an 8-channel electromagnetic relay module used in semiconductor equipment to achieve isolated switching between digital control signals and high voltage/high current loads. It can communicate with PLC and upper computer through RS-232/RS-485 to achieve remote or automatic control.

key parameters

Project Indicator Description

8 channels, each independently controlled

SPDT (NO/NC/COM) contact form allows flexible selection of normally open or normally closed output

Contact capacity AC 250V/2A; Rated value of DC 30V/2A resistive load

Control signal optocoupler isolation, 3.3-24VDC compatible with TTL/CMOS levels

Communication interface RS-232/RS-485/422 baud rate 2400-19200bps optional

Supply voltage 24VDC (18-36VDC) Industrial standard voltage range

Response time suction ≤ 15ms; release ≤ 10ms, fast and stable switching

Operating temperature -10 ℃ -60 ℃ Suitable for industrial environments

Installation method: Standard 35mm rail/panel installation for easy maintenance and expansion

Features

Isolation protection: The optocoupler isolates the control circuit from the load circuit to prevent interference and surges.

Multi protocol communication: Supports RS-232/485/422, making it easy to access different control systems.

Intuitive status indication: Each channel is equipped with LED indicator lights to display the working status in real time.

Address/baud rate adjustable: Set the address (0-255) and baud rate (2400-19200bps) through a dip switch, supporting multi module networking.

Low power design: Static power consumption<5W, suitable for long-term stable operation.

Typical Applications

Semiconductor equipment gas valve, vacuum pump, heating element control

Power switching and safety interlocking in photovoltaic manufacturing

I/O Expansion and Remote Control of Automated Production Lines

Multi channel switch control in industrial environment

AMAT Applied Materials 0100-09307继电器模块 产品展示

 产品视频
