AMAT Applied Materials 0100-09110过滤板

AMAT Applied Materials 0100-09110过滤板

1.产 品 资 料 介 绍：

核心规格

功能特点

• 信号滤波：集成低通、带通滤波器，抑制高频噪声干扰。
• 电源分配：独立电源层，降低电源噪声对信号的影响。
• 抗干扰设计：多层接地与屏蔽，增强抗电磁干扰能力。
• 小型化结构：体积小、重量轻，适用于空间受限的设备。

应用场景

• 半导体薄膜沉积、刻蚀、离子注入设备的控制与信号处理模块。
• 真空系统、气体流量控制、温度监测等子系统电路。

更换与注意事项

1. 确认版本：核对物料编码 0100‑09110 与版本号（常见 Rev F），确保电气兼容。
2. 防静电：佩戴防静电手环，在防静电台垫上操作。
3. 安装定位：按机箱定位孔与接插件方向安装，避免错位。
4. 焊接要求：回流焊峰值 245～255℃，波峰焊 250～260℃，防止板材分层。
5. 测试：安装后进行电源、信号完整性与功能测试，确保无短路或信号异常。

AMAT Applied Materials 0100-09110过滤板 英文资料：

AMAT 0100-09110 is a "Mini Filter PCB Board" specifically designed for semiconductor equipment. It is mainly used for signal filtering, noise suppression, and power distribution to ensure stable operation of the equipment in high electromagnetic interference environments.

Core specifications

Project specifications/parameter notes

Type 4 Rigid PCB Signal and Power Layered Design

Size approximately 147 mm x 51.5 mm x 11.4 mm, compatible with standard chassis

High TG FR-4 substrate, high temperature resistance and anti-interference

Surface treatment ENIG (chemical nickel/immersion gold) for high reliability and weldability

Minimum line width/line spacing 0.10 mm/0.10 mm high-density wiring

Minimum aperture of 0.20 mm (PTH) compatible with BGA and other devices

Working temperature -20~+60 ℃ Industrial environment

Certification of CE, UL, RoHS international safety standards

Features

Signal filtering: Integrated low-pass and band-pass filters to suppress high-frequency noise interference.

Power distribution: Independent power layer to reduce the impact of power noise on signals.

Anti interference design: multi-layer grounding and shielding to enhance the ability to resist electromagnetic interference.

Compact structure: small in size and light in weight, suitable for devices with limited space.

Application scenarios

Control and signal processing modules for semiconductor thin film deposition, etching, and ion implantation equipment.

Subsystem circuits for vacuum system, gas flow control, temperature monitoring, etc.

Replacement and precautions

Confirm version: Verify the material code 0100-09110 with the version number (commonly Rev F) to ensure electrical compatibility.

Anti static: Wear an anti-static wristband and and operate on the anti-static mat.

Installation positioning: Install according to the chassis positioning hole and connector direction to avoid misalignment.

Welding requirements: Reflow peak temperature 245-255 ℃, wave soldering 250-260 ℃, to prevent delamination of the plate.

Testing: Conduct power, signal integrity, and functional testing after installation to ensure no short circuits or signal abnormalities.

AMAT Applied Materials 0100-09110过滤板 产品展示

 产品视频
