AMAT Applied Materials 0130-00525显示I/O模块
1.产 品 资 料 介 绍：
核心规格
功能与优势
应用场景
更换与注意事项
AMAT Applied Materials AS01391-21-1印刷电路板 英文资料：
The AMAT 0130-00525 Display I/O Module is a high-performance input/output component designed by Applied Materials specifically for semiconductor device operation interfaces. It is used to connect display and control devices such as touch screens, indicator lights, buttons, etc. It is commonly used in control panel systems on platforms such as Centura, Endura, P5000, etc.
Core specifications
Project specifications/characteristics remarks
Type display/control I/O interface PCB integrates input acquisition and output driver
Input channel 16 digital inputs can be expanded to 32 channels
Output channel 16 digital quantity output part channels can be equipped with relays
Input signal 5-24 VDC contact/level compatible with multiple buttons and sensors
Output signal 5-30 VDC/500 mA (transistor), direct drive indicator light, small relay
Parallel RGB/TTL or LVDS display interface supports 3.5 "~10.4" touch screen
Communication interfaces RS-485, SPI, and I ² C are convenient for interfacing with the main controller
High precision measurement with a resolution of 0.1 ℃
Working temperature -20~+60 ℃, suitable for industrial grade environment
Installation method: Standard 35mm guide rail or panel fixed for easy maintenance and replacement
Certified CE, UL, RoHS compliant with international safety standards
Features and advantages
Integrated design: Simultaneously processing display signals and I/O control, reducing the number of wiring and interface modules.
High resolution display: Supports resolutions above 800 × 600, with clear and stable images.
Multi channel I/O: 16 inputs and 16 outputs, meeting the requirements of panel operation and status indication.
High reliability: adopting photoelectric isolation and overvoltage protection, with strong anti-interference ability.
Easy to integrate: Supports multiple communication protocols, making it convenient to access existing control systems.
Application scenarios
Semiconductor equipment operation panel
Vacuum system status monitoring
Human computer interaction interface for thin film deposition, etching, and ion implantation equipment
Replacement and precautions
Confirm version: Verify the material code 0130-00525 with the version number to ensure electrical compatibility.
Anti static: Wear an anti-static wristband and and operate on the anti-static mat.
Installation positioning: Install according to the chassis positioning hole and connector direction to avoid misalignment.
Wiring connection: Connect the touch screen, buttons, indicator lights, and power supply according to the terminal identification, paying attention to polarity and shielding.
Testing: Conduct power, signal integrity, and functional testing after installation to ensure no short circuits or signal abnormalities.
AMAT Applied Materials AS01391-21-1印刷电路板 产品展示
