AMAT Applied Materials 0100-90043接口模块

AMAT Applied Materials    0100-90043接口模块

1.产 品 资 料 介 绍：

核心规格

结构与原理

1. 协议转换：支持 RS‑232↔RS‑485、RS‑232↔RS‑422 等模式。
2. 光耦隔离：实现输入与输出电气隔离，防止信号干扰。
3. 电平转换：兼容 3.3V/5V/12V 等不同电平信号。
4. 配置方式：通过拨码开关设置通信模式、地址与波特率。

AMAT Applied Materials  0100-90043接口模块 英文资料：

AMAT 0100-90043 is an RS-232/RS-485/RS-422 multifunctional interface module used for signal conversion and isolation between different communication protocol devices in semiconductor equipment. It supports point-to-point or multi-point topology, baud rate of 1200 bps~115.2 kbps, working voltage of DC 24V ± 10%, protection level of IP20, size of 100 × 60 × 30mm, can be installed on rails or screws, and is suitable for automation control systems on platforms such as Endura and Centura.

Core specifications

Project Specification Description

Functional positioning serial communication protocol conversion and electrical isolation compatible with multiple industrial standard interfaces

The communication interface RS-232/RS-485/RS-422 can be selected as the interface type through a dip switch

Number of channels: 1 channel supports one-way or two-way data transmission

Transmission rate 1200 bps~115.2 kbps default 19.2 kbps, software configurable

Isolation voltage of 1500Vrms effectively suppresses ground circulation interference

Working voltage DC 24V ± 10%, typical power consumption ≤ 5W

Working temperature range of 0 ℃~50 ℃ is suitable for semiconductor workshop environment

Interface type DB9 male/female head optional; Terminal block adapts to different device connection methods

Material and protective shell: ABS+PC; Protection level: IP20 dust proof, suitable for installation inside electrical control boxes

Size and installation 100 × 60 × 30mm, flexible installation with 35mm guide rail or M3 screws for easy maintenance

Structure and Principle

This module consists of a protocol conversion circuit, high-speed optocoupler isolation, and level conversion chip:

Protocol conversion: Supports RS-232 ↔ RS‑485、RS‑232 ↔ RS-422 and other modes.

Optocoupler isolation: achieve electrical isolation between input and output to prevent signal interference.

Level conversion: compatible with signals of different levels such as 3.3V/5V/12V.

Configuration method: Set the communication mode, address, and baud rate through the dip switch.

 AMAT Applied Materials   0100-90043接口模块 产品展示

 产品视频
