AMAT Applied Materials 46-406121-01背板
1.产 品 资 料 介 绍：
- 适用系统：优先适配 AMAT Endura 系列 PVD 设备，兼容 AMAT 同类半导体薄膜沉积设备的模块互联系统
- 接口配置：16 路标准板卡插槽（支持热插拔模块），集成 2 路电源分配接口（主 / 备冗余）、4 路高速通信总线接口
- 信号性能：支持数字量（24V DC）、模拟量（4-20mA）及高速差分信号传输，信号延迟≤50ns
- 电源分配：输入电压 DC 24V/48V 双路兼容，单路输出电流≤20A，具备过载保护（25A 触发）
- 物理尺寸：长 350mm× 宽 200mm× 高 20mm，安装孔位适配原厂设备 chassis 支架，M4 螺丝固定
- 环境适应：工作温度 - 5℃-65℃，相对湿度≤90% RH（无凝露），抗电磁干扰符合 EN 61000-6-2 标准
- 信号集成高效：高密度插槽设计减少模块间布线复杂度，高速总线接口保障多模块数据同步传输，避免信号冲突
- 原厂无缝兼容：插槽定义、连接器引脚与原厂设备完全匹配，模块插拔兼容性 100%，替换后无需重新配置互联参数
- 高可靠冗余：双路电源分配独立供电，单路故障时自动切换，背板电路采用镀金触点连接器，插拔寿命≥500 次
AMAT Applied Materials 46-406121-01背板 英文资料：
1、 Product Overview
The AMAT 46-406121-01 backplane is the modular signal interconnection core of semiconductor PVD/CVD equipment (such as AMAT Endura series coating machines), mainly responsible for the signal aggregation and distribution functions of the equipment's main control unit and functional modules (such as drive modules and detection modules), realizing bidirectional interaction of power supply, data transmission, and control instructions. It adopts a high-density connector layout and anti-interference design, which is suitable for the multi module collaborative work requirements of semiconductor equipment. It can directly ｒｅｐｌａｃｅ the same type of backplane from the original factory without adjusting the internal wiring logic of the equipment.
2、 Key parameters
Applicable system: Priority adaptation to AMAT Endura series PVD equipment, compatible with module interconnection systems of similar AMAT semiconductor thin film deposition equipment
Interface configuration: 16 standard card slots (supporting hot swappable modules), integrated with 2 power distribution interfaces (primary/backup redundancy) and 4 high-speed communication bus interfaces
Signal performance: Supports digital (24V DC), analog (4-20mA), and high-speed differential signal transmission, with signal delay ≤ 50ns
Power distribution: Input voltage DC 24V/48V dual compatible, single output current ≤ 20A, with overload protection (triggered by 25A)
Physical dimensions: 350mm in length, 200mm in width, and 20mm in height. The installation holes are compatible with the original equipment chassis bracket and fixed with M4 screws
Environmental adaptation: Working temperature -5 ℃ -65 ℃, relative humidity ≤ 90% RH (no condensation), anti electromagnetic interference in accordance with EN 61000-6-2 standard
3、 Core advantages
Efficient signal integration: high-density slot design reduces wiring complexity between modules, high-speed bus interface ensures synchronous transmission of data from multiple modules, and avoids signal conflicts
Factory seamless compatibility: slot definition, connector pins are fully matched with the original equipment, module plug-in compatibility is 100%, and there is no need to reconfigure interconnection parameters after replacement
High reliability redundancy: dual power distribution for independent power supply, automatic switching in case of single channel failure. The backplane circuit adopts gold-plated contact connectors, with a plug-in life of ≥ 500 times
AMAT Applied Materials 46-406121-01背板 产品展示
产品视频
