AMAT Applied Materials 0120-00794过程传感器主板
1.产 品 资 料 介 绍：
- 集成 8-16 路传感器接口，支持热电偶（K/J 型）、RTD（铂电阻）、4-20mA 模拟信号输入，可同步采集温度、压力、流量等工艺参数，16 位 ADC 转换精度，测量误差≤±0.1% FS。
- 具备信号滤波与冷端补偿功能，能抑制车间电磁干扰，温度采集范围 - 200~1300℃，适配半导体蚀刻、沉积工艺的高精度监测需求。
- 配备 RS485/Modbus 接口，可直接对接 AMAT 0190-24007 单板计算机、20-000314-003 模拟输入模块，实时上传采集数据，支持远程校准传感器参数。
- 预留 2 路数字量输出接口，可联动控制阀门、加热器等执行元件，形成工艺参数监测 - 控制闭环，提升设备自动化程度。
- 工作温度 - 20~+70℃，湿度 5%-95%（无凝露），防护等级 IP20，表面防静电喷涂，适配半导体洁净车间温湿度波动与粉尘控制要求。
- 采用光电隔离技术（隔离电压≥2500V DC），抗电磁干扰符合 EN 55022 Class B，避免射频设备干扰导致的信号失真。
- 核心芯片选用工业级型号，经 10 万次循环采集测试，MTBF≥8 万小时，支持 7×24 小时连续运行，适配半导体工厂高稼动率需求。
- 符合 UL/CE/RoHS 认证，原厂提供 1-3 年质保，支持快速备件更换，减少因主板故障导致的设备停机时间。
AMAT Applied Materials 0120-00794过程传感器主板 英文资料：
1. Signal acquisition performance (AMAT 0120-00794)
Integrate 8-16 sensor interfaces, support thermocouple (K/J type), RTD (platinum resistance), 4-20mA analog signal input, can synchronously collect process parameters such as temperature, pressure, flow rate, etc., 16 bit ADC conversion accuracy, measurement error ≤ ± 0.1% FS
Equipped with signal filtering and cold junction compensation functions, it can suppress electromagnetic interference in the workshop, with a temperature acquisition range of -200~1300 ℃, suitable for high-precision monitoring requirements of semiconductor etching and deposition processes.
2. Adaptation and linkage (AMAT 0120-00794)
Equipped with RS485/Modbus interface, it can directly interface with AMAT 0190-24007 single board computer and 20-000314-003 analog input module, upload and collect data in real time, and support remote calibration of sensor parameters.
Reserve 2 digital output interfaces, which can be linked to control valve, heater and other actuating components, forming a process parameter monitoring control loop and improving equipment automation.
3. Environment and Protection (AMAT 0120-00794)
Working temperature -20~+70 ℃, humidity 5% -95% (no condensation), protection level IP20, surface anti-static spraying, suitable for temperature and humidity fluctuations and dust control requirements in semiconductor clean workshops.
Adopting optoelectronic isolation technology (isolation voltage ≥ 2500V DC), anti electromagnetic interference complies with EN 55022 Class B, avoiding signal distortion caused by RF equipment interference.
4. Reliability (AMAT 0120-00794)
The core chip is selected from industrial grade models, which have undergone 100000 cycles of data collection and testing. The MTBF is ≥ 80000 hours and supports continuous operation for 7 × 24 hours, meeting the high utilization requirements of semiconductor factories.
Compliant with UL/CE/RoHS certification, the original factory provides a 1-3 year warranty, supports quick replacement of spare parts, and reduces equipment downtime caused by motherboard failures.
AMAT Applied Materials 0120-00794过程传感器主板 产品展示
