AMAT Applied Materials 0100-09099互连组件
1.产 品 资 料 介 绍：
- 作为腔体接口板，集成多类型接口适配半导体设备反应腔组件，支持模拟信号（4-20mA）、数字 I/O 信号及电源信号的集中转接，兼容热电偶、压力传感器等外设连接。
- 采用 PCB 板载式端子与针脚设计，接口间距符合工业标准，可直接对接 0100-09008 气动控制板、0120-00794 过程传感器主板等 AMAT 设备模块，无需额外转接件。
- 具备信号整形与中继功能，可优化长距离传输后的信号质量，减少衰减，支持 Modbus 协议信号中转，助力反应腔数据与 0190-24007 单板计算机的实时交互。
- 承担腔体与设备主控系统的 “信号桥梁” 角色，实现工艺参数采集、控制指令下发的双向传输，适配蚀刻、沉积等工艺的腔体闭环控制需求。
- 工作温度覆盖 - 20~+70℃，湿度耐受 5%-95%（无凝露），表面经防静电喷涂处理，符合 Class 100 洁净室粉尘控制要求，适配反应腔周边严苛环境。
- 采用 PCB 板分层屏蔽设计，抗电磁干扰符合 EN 55022 Class B 标准，避免射频设备干扰导致的信号失真，防护等级达 IP20。
- 核心接口部件选用工业级材质，经 10 万次插拔与信号传输测试，接触电阻≤50mΩ，支持 7×24 小时连续运行，MTBF≥8 万小时。
- 符合 UL/CE/RoHS 认证，适配半导体设备高稼动率需求，原厂提供 1-3 年质保，备件可快速替换以缩短停机时间。
AMAT Applied Materials 0100-09099互连组件 英文资料：
1. Interface adaptation performance (AMAT 0100-09099)
As a cavity interface board, it integrates multiple types of interfaces to adapt to semiconductor device reaction cavity components, supports centralized conversion of analog signals (4-20mA), digital I/O signals, and power signals, and is compatible with external connections such as thermocouples and pressure sensors.
Adopting PCB board mounted terminal and pin design, the interface spacing meets industrial standards, and can directly interface with AMAT equipment modules such as 0100-09008 pneumatic control board and 0120-00794 process sensor motherboard without the need for additional adapters.
2. Signal Transmission and Linkage (AMAT 0100-09099)
Equipped with signal shaping and relay functions, it can optimize the signal quality after long-distance transmission, reduce attenuation, support Modbus protocol signal relay, and assist in real-time interaction between reaction chamber data and 0190-24007 single board computer.
Undertake the role of a "signal bridge" between the cavity and the equipment control system, achieve bidirectional transmission of process parameter acquisition and control command issuance, and adapt to the closed-loop control requirements of cavity processes such as etching and deposition.
3. Environment and Protection (AMAT 0100-09099)
The working temperature covers -20~+70 ℃, with a humidity tolerance of 5% -95% (no condensation). The surface has been treated with anti-static spraying, which meets the dust control requirements of Class 100 cleanroom and is suitable for harsh environments around the reaction chamber.
Adopting a PCB board layered shielding design, the anti electromagnetic interference meets the EN 55022 Class B standard, avoiding signal distortion caused by RF equipment interference, and the protection level reaches IP20.
4. Reliability (AMAT 0100-09099)
The core interface components are made of industrial grade materials and have undergone 100000 cycles of plugging and signal transmission testing. The contact resistance is ≤ 50m Ω, and it supports 7 × 24-hour continuous operation with an MTBF of ≥ 80000 hours.
Compliant with UL/CE/RoHS certification, suitable for high utilization requirements of semiconductor equipment, original factory provides 1-3 year warranty, and spare parts can be quickly replaced to shorten downtime.
