AMAT Applied Materials 0100-00156隔离放大器
1.产 品 资 料 介 绍：
- 设备适配：匹配 AMAT 半导体工艺设备（如蚀刻、沉积机台），用于传感器（如压力、温度传感器）与主控单元间的信号隔离放大，避免干扰信号影响控制精度。
- 工艺兼容：聚焦半导体洁净车间强电磁环境，适配真空腔室压力监测、反应气体流量信号处理等场景，支持与 AMAT 设备 PLC 系统无缝对接。
- 核心功能：实现模拟信号（如 0-5V、4-20mA）的电气隔离与线性放大，阻断高低压回路干扰，保障工艺参数采集与传输的准确性。
- 隔离性能：隔离电压≥2500VDC（输入 - 输出）、≥1500VDC（输入 - 电源），隔离电阻≥10¹²Ω，有效阻断共模干扰与接地环路噪声。
- 放大精度：电压增益误差≤0.1%，非线性误差≤0.05% FS，温漂≤50ppm/℃（-20-60℃），确保信号放大后仍保持高线性度，适配 3x 纳米制程参数监测需求。
- 信号兼容：输入支持 0-10V 电压信号、4-20mA 电流信号，输出可通过拨码开关设置为 0-5V/0-10V/4-20mA，适配不同传感器与主控单元的信号规格。
- 防护设计：外壳采用工业级阻燃 ABS 材质，具备防静电（ESD）、防电磁干扰（EMI）设计，通过 EMC 测试（EN 55032 Class B），适应车间复杂电磁环境。
- 安装适配：紧凑型结构（尺寸约 80×50×20mm），支持 DIN35mm 导轨式安装，接线端子带螺丝锁固设计，防止振动导致的接线松动。
- 维护便利：配备电源、信号状态指示灯，支持通过万用表直接测量输出信号判断模块工况，无需拆解设备即可初步排查故障。
AMAT Applied Materials 0100-00156隔离放大器 英文资料：
1. Adaptation scenarios and functions (0100-00156)
Equipment adaptation: Matching AMAT semiconductor process equipment (such as etching and deposition machines), used for signal isolation and amplification between sensors (such as pressure and temperature sensors) and the main control unit to avoid interference signals affecting control accuracy.
Process compatibility: Focusing on the strong electromagnetic environment of semiconductor clean workshops, adapting to scenarios such as vacuum chamber pressure monitoring and reaction gas flow signal processing, supporting seamless integration with AMAT equipment PLC systems.
Core function: Implement electrical isolation and linear amplification of analog signals (such as 0-5V, 4-20mA), block high and low voltage circuit interference, and ensure the accuracy of process parameter acquisition and transmission.
2. Accuracy and Performance (0100-00156)
Isolation performance: Isolation voltage ≥ 2500VDC (input-output), ≥ 1500VDC (input-output), isolation resistance ≥ 10 ¹² Ω, effectively blocking common mode interference and ground loop noise.
Amplification accuracy: Voltage gain error ≤ 0.1%, non-linear error ≤ 0.05% FS, temperature drift ≤ 50ppm/℃ (-20-60 ℃), ensuring high linearity even after signal amplification, suitable for 3x nanometer process parameter monitoring requirements.
Signal compatibility: the input supports 0-10V voltage signal, 4-20mA current signal, and the output can be set to 0-5V/0-10V/4-20mA through the dial switch to adapt to the signal specifications of different sensors and the main control unit.
3. Structure and Protection (0100-00156)
Protection design: The shell is made of industrial grade flame-retardant ABS material, with anti-static (ESD) and electromagnetic interference (EMI) design, and has passed EMC testing (EN 55032 Class B) to adapt to the complex electromagnetic environment in the workshop.
Installation adaptation: Compact structure (size approximately 80 × 50 × 20mm), supporting DIN35mm rail installation, with screw locking design for wiring terminals to prevent loose wiring caused by vibration.
Easy maintenance: equipped with power supply and signal status indicator lights, supporting direct measurement of output signals through a multimeter to determine module operating conditions, without the need to disassemble the equipment for preliminary troubleshooting.
