BENTLY 3500/22M 138607-01 瞬态数据接口
1.产 品 资 料 介 绍：
- 瞬态数据采集超精准：BENTLY 3500/22M（138607-01）是专业瞬态数据接口，能快速采集旋转机械的振动、转速、位移等瞬态数据，比如汽轮机的突发振动信号、电机的转速波动数据，捕捉速度快且数据精度高，为设备故障分析提供准确依据。
- 适配 3500 监测系统：专为 BENTLY 3500 机械保护系统设计，能无缝对接 3500 系列监测模块，不用额外调试就能接入现有系统，快速扩展瞬态数据采集功能，特别适合电厂、化工厂等依赖 3500 系统的场景。
- 多信号类型兼容：支持振动、位移、转速等多种模拟量与数字量信号输入，能连接加速度传感器、涡流探头等不同类型监测设备，不用更换接口就能采集多维度机械数据，适配性强。
- 恶劣环境稳运行：能在 0℃~65℃温度范围工作，防尘防潮且抗电磁干扰，工业现场的粉尘、潮湿环境，以及设备运行时的电磁辐射，都不会影响其数据采集稳定性，不易出故障。
- 数据传输速度快：具备高速数据传输能力，采集到的瞬态数据能快速传输到上位机或数据分析系统，比如设备突发异常时，能及时将振动峰值数据传至监控平台，为紧急处置争取时间。
- 模块化安装省空间：采用 BENTLY 3500 系统标准模块化设计，能直接安装在 3500 框架中，与其他监测模块紧凑布局，不额外占用控制柜空间，适合系统集成化程度高的场景。
- 故障预警易排查：带状态指示灯，电源通断、数据传输是否正常、接口是否故障，看灯就能初步判断；还能通过系统反馈故障代码，维修人员不用逐个检测线路，快速定位问题，缩短排查时间。
- 宽压供电易适配：支持 24V 直流标准工业电源，和现场常用的控制柜电源直接匹配，不用额外定制专用电源，接线简单，安装时不用反复调整供电参数，省时省力。
- 数据存储助分析：可配合系统实现瞬态数据临时存储，当设备出现异常时，能保存故障前后的关键数据，后续分析故障原因、追溯故障过程时，有完整数据支撑，方便精准诊断。
- 合规性与耐用性双保障：符合工业设备安全认证标准，采用工业级耐磨、抗腐蚀材质，能承受机械振动与现场冲击，平均无故障时间长，长期在旋转机械监测场景使用也省心，减少维护成本。
BENTLY 3500/22M 138607-01 瞬态数据接口 英文资料：
Ultra precise transient data acquisition: BENTLY 3500/22M (138607-01) is a professional transient data interface that can quickly collect transient data such as vibration, speed, displacement, etc. of rotating machinery, such as sudden vibration signals of steam turbines and speed fluctuation data of motors. It captures data quickly and accurately, providing accurate basis for equipment fault analysis.
Compatible with 3500 Monitoring System: Designed specifically for BENTLY 3500 mechanical protection systems, it can seamlessly integrate with 3500 series monitoring modules without additional debugging to quickly expand transient data acquisition capabilities. It is particularly suitable for scenarios such as power plants and chemical plants that rely on the 3500 system.
Multi signal type compatibility: supports various analog and digital signal inputs such as vibration, displacement, and speed, and can connect different types of monitoring devices such as acceleration sensors and eddy current probes. It can collect multi-dimensional mechanical data without changing interfaces and has strong adaptability.
Stable operation in harsh environments: capable of working within a temperature range of 0 ℃~65 ℃, dustproof, moisture-proof, and resistant to electromagnetic interference. The dust, humid environment in industrial sites, as well as electromagnetic radiation during equipment operation, will not affect its data acquisition stability and are not prone to malfunctions.
Fast data transmission speed: With high-speed data transmission capability, the collected transient data can be quickly transmitted to the upper computer or data analysis system. For example, in case of sudden equipment abnormalities, the vibration peak data can be promptly transmitted to the monitoring platform to buy time for emergency response.
Modular installation saves space: Adopting the BENTLY 3500 system standard modular design, it can be directly installed in the 3500 framework, with a compact layout with other monitoring modules, without occupying additional control cabinet space, suitable for scenarios with high system integration.
Fault warning and easy troubleshooting: equipped with status indicator lights, whether the power supply is on or off, whether data transmission is normal, and whether the interface is faulty can be preliminarily judged by looking at the lights; It can also provide feedback on fault codes through the system, so that maintenance personnel do not need to inspect each line one by one, quickly locate the problem, and shorten the troubleshooting time.
Wide voltage power supply easy to adapt: supports 24V DC standard industrial power supply, directly matches with commonly used control cabinet power supply on site, no need to customize special power supply, simple wiring, no need to repeatedly adjust power supply parameters during installation, saving time and effort.
Data storage assistance analysis: It can be used in conjunction with the system to temporarily store transient data. When the device encounters an abnormality, it can save key data before and after the fault. When analyzing the cause of the fault and tracing the fault process, it has complete data support, which facilitates accurate diagnosis.
Dual guarantee of compliance and durability: Compliant with industrial equipment safety certification standards, made of industrial grade wear-resistant and corrosion-resistant materials, capable of withstanding mechanical vibration and on-site impact, with a long average time between failures. Long term use in rotating machinery monitoring scenarios is also worry free, reducing maintenance costs.
BENTLY 3500/22M 138607-01 瞬态数据接口 产品展示
产品视频
