CM400YQ逻辑控制器

CM400YQ逻辑控制器

1.产 品 资 料 介 绍：

CM400YQ逻辑控制器产品特点

1.  搭载高性能工业级处理器，运算速度达50ns/指令，可快速响应复杂逻辑控制需求，保障控制精度。

2.  配置8路独立隔离数字量输出通道，支持常开触点切换，适配5-30VDC/5-250VAC宽电压负载设备。

3.  每路输出通道阻性负载承载能力达4A，先导负载达2A，UL安装标准下总负载电流可达30A（随温度调整）。

4.  输出通道开/关切换典型响应时间仅15ms，可高效适配高速分拣、精准启停等对时效性要求高的场景。

各输出通道间独立隔离设计，且通道与系统地高效隔离，强效抵御电磁干扰，避免信号串扰。

6.  集成RJ45、RS422、CAN多通讯接口，可无缝对接上位机与各类传感设备，实现数据高效交互。

7.  支持梯形图、功能块图等多种编程方式，兼容主流工业控制软件，编程调试灵活便捷。

8.  内置完善故障诊断功能，可实时监测通道状态、通讯链路，异常时快速报警并反馈故障信息。

9.  工作温度适配范围-20℃~60℃，湿度5%~95%无凝露，耐受工业现场复杂温湿度环境。

10. 采用模块化结构设计，支持I/O扩展，可根据控制需求灵活增减通道数量，拓展性强。

11. 外壳选用高强度阻燃材质，防护等级达IP20，抗冲击、抗振动性能符合工业级严苛标准。

12. 适配TS-35标准DIN导轨安装，体积紧凑，可密集部署于电控柜，节省安装空间与布线成本。

13. 支持本地手动调试与远程集中控制双模式，运维人员可按需切换，提升运维效率。

14. 平均无故障时间（MTBF）超400000小时，经全流程稳定性测试，运行可靠且使用寿命长。

15. 配备清晰状态指示灯与故障告警灯，直观反馈设备运行状态，便于快速排查与维护。

CM400YQ逻辑控制器  英文资料：

CM400YQ Logic Controller Product Features

1. Equipped with a high-performance industrial grade processor with a processing speed of 50ns/instruction, it can quickly respond to complex logic control requirements and ensure control accuracy.

2. Configure 8 independent isolated digital output channels, support normally open contact switching, and adapt to 5-30VDC/5-250VAC wide voltage load devices.

3. The resistive load carrying capacity of each output channel reaches 4A, the pilot load reaches 2A, and the total load current under UL installation standards can reach 30A (adjusted with temperature).

4. The typical response time for switching the output channel on/off is only 15ms, which can efficiently adapt to scenarios with high timeliness requirements such as high-speed sorting and precise start stop.

Each output channel is designed with independent isolation, and the channels are efficiently isolated from the system ground, effectively resisting electromagnetic interference and avoiding signal crosstalk.

6. Integrated RJ45, RS422, and CAN multiple communication interfaces can seamlessly connect with the upper computer and various sensing devices, achieving efficient data exchange.

7. Supports multiple programming methods such as ladder diagrams and functional block diagrams, compatible with mainstream industrial control software, and flexible and convenient programming and debugging.

8. Built in comprehensive fault diagnosis function, which can monitor channel status and communication links in real time, quickly alarm and feedback fault information in case of abnormalities.

9. The working temperature adaptation range is -20 ℃~60 ℃, with a humidity of 5%~95% and no condensation. It can withstand complex temperature and humidity environments in industrial sites.

10. Adopting a modular structure design, supporting I/O expansion, the number of channels can be flexibly increased or decreased according to control requirements, with strong expandability.

11. The shell is made of high-strength flame-retardant material, with a protection level of IP20, and its impact and vibration resistance meet the strict industrial standards.

12. Suitable for TS-35 standard DIN rail installation, compact in size, can be densely deployed in electrical control cabinets, saving installation space and wiring costs.

13. Supports dual modes of local manual debugging and remote centralized control, allowing operation and maintenance personnel to switch as needed to improve operation and maintenance efficiency.

14. The mean time between failures (MTBF) exceeds 400000 hours, and after full process stability testing, it operates reliably and has a long service life.

15. Equipped with clear status indicator lights and fault alarm lights, providing intuitive feedback on equipment operation status for quick troubleshooting and maintenance.

CM400YQ逻辑控制器  产品展示

产品视频
