P0400ZG接口模块

P0400ZG接口模块

1.产 品 资 料 介 绍：

1. 提供 NBI 节点总线、RS485 及系统总线三种接口，实现多总线互联。
2. 兼容 Foxboro 私有节点总线协议与 Modbus RTU，支持多品牌现场设备接入。
3. 通信速率 2400/4800/9600/19200bps 软件可调，适配不同现场带宽需求。
4. 最大支持 32 个分布式节点接入，支持分期扩展与在线配置。
5. 单节点数据传输延迟≤5ms，满足实时控制要求。
6. 24VDC（±10%）供电，典型功耗≤5W，节能适配现场安装。
7. 内置过压、过流及电磁干扰保护，提升数据传输安全性。
8. 工作温度 - 40℃至 70℃、湿度 0–95% 无凝结，适应宽温高湿工业环境。
9. 压铸铝外壳 + IP20 防护等级，耐受 G3 级振动与高粉尘场景。
10. 支持节点在线激活、休眠与故障隔离，降低运维复杂度。
11. 可通过专用配置软件或 Modbus 协议灵活设置节点参数。
12. 结构紧凑，与 I/A Series 系列模块无缝兼容，便于系统集成。
13. 具备数据校验机制，保障节点与系统间数据一致性。
14. 支持远程节点管理，减少现场布线成本与施工工作量。
15. 长期运行稳定，故障率低，保障石油化工、电力等连续生产。

P0400ZG接口模块  产品英文

P0400ZG is a node bus NBI interface module of Schneider Foxboro I/A Series system, responsible for protocol conversion, data transmission, and node management between node bus and system bus, adapting to the distributed I/O networking requirements of process automation sites.

Provide three interfaces: NBI node bus, RS485, and system bus to achieve multi bus interconnection.

Compatible with Foxboro private node bus protocol and Modbus RTU, supporting multi brand field device access.

The communication speed is 2400/4800/9600/19200bps, which can be adjusted by software to meet different on-site bandwidth requirements.

Supports up to 32 distributed nodes for access, supports phased expansion and online configuration.

Single node data transmission delay ≤ 5ms, meeting real-time control requirements.

24VDC (± 10%) power supply, typical power consumption ≤ 5W, energy-saving and suitable for on-site installation.

Built in overvoltage, overcurrent, and electromagnetic interference protection to enhance data transmission security.

Working temperature -40 ℃ to 70 ℃, humidity 0-95% without condensation, suitable for wide temperature and high humidity industrial environments.

Die cast aluminum casing with IP20 protection level, capable of withstanding G3 level vibration and high dust scenarios.

Support online activation, sleep, and fault isolation of nodes to reduce operational complexity.

Node parameters can be flexibly set through dedicated configuration software or Modbus protocol.

Compact structure, seamlessly compatible with I/A Series modules, facilitating system integration.

Equipped with a data verification mechanism to ensure data consistency between nodes and systems.

Support remote node management to reduce on-site wiring costs and construction workload.

Long term stable operation, low failure rate, ensuring continuous production of petrochemicals, electricity, and other industries.

This interface module has stable communication and strong scalability, and is a key component of distributed networking in I/A Series systems, suitable for multi industry process control scenarios.

P0400ZG接口模块  产品展示
