HIMA F3315接口模块

HIMA F3315接口模块

1.产 品 资 料 介 绍：

核心定位与安全特性

• 属于 HIMatrix F3 系列安全接口模块，故障安全设计，适配 SIL 3 安全系统。
• 符合 IEC 61508 SIL 3、ISO 13849 PLe，通过 TÜV 认证。
• 采用四重化（QMR）架构，单通道故障不影响系统安全运行。

硬件与电气参数

1. 通信接口：标配 2×RJ45，支持 10/100Mbps 以太网。
2. 通信协议：支持 SafeEthernet（安全以太网）、Profisafe、Modbus TCP 等安全协议。
3. 供电：24VDC（-15%~+20%），具备反极性与过流保护。
4. 隔离：通信端口与背板电气隔离，耐压 ≥ 2.5kV。
5. 诊断：实时监测通信链路、端口状态，故障可定位至通道级。
6. 响应时间：通信延迟 ≤ 1ms，满足高速安全联锁要求。
7. 环境：工作温度 -20℃~+60℃，防护等级 IP20，DIN 导轨安装。

功能与系统特性

• 安全通信：实现控制器与远程 I/O 模块的安全数据传输，支持冗余通信。
• 数据交互：与 DCS、PLC 等上位系统进行安全数据交换，支持 SOE 事件记录。
• 热插拔：支持在线更换，维护不中断安全系统运行。
• 时间同步：支持 SNTP 协议，确保系统时间统一。
• 兼容性：适配 F35、F60 等 HIMatrix 控制器，兼容 F32/F33 系列 I/O 模块。

典型应用场景

• 石油化工：ESD 紧急停车系统、SIS 安全仪表系统、反应器联锁。
• 油气能源：长输管线安全控制、海上平台安全通信、火炬系统。
• 电力行业：锅炉保护、汽轮机超速停机、发电机安全控制。
• 制造业：机器人安全门、生产线急停、高速包装机安全通信。

HIMA F3315接口模块  英文资料：

HIMA F3315 is a safety communication/interface module of the HIMatrix F3 series, used for safety communication and data exchange between safety controllers, remote I/O, and upper level systems, meeting SIL 3 safety level.

Core positioning and security features

Belonging to the HIMatrix F3 series safety interface module, designed for fault safety and compatible with SIL 3 safety systems.

Compliant with IEC 61508 SIL 3, ISO 13849 PLe, and certified by T Ü V.

Adopting a quadruple normalization (QMR) architecture, single channel failures do not affect the safe operation of the system.

Hardware and electrical parameters

Communication interface: Standard configuration includes 2 x RJ45 and supports 10/100Mbps Ethernet.

Communication protocol: Supports secure protocols such as SafeEthernet, Profisafe, Modbus TCP, etc.

Power supply: 24VDC (-15%~+20%), with reverse polarity and overcurrent protection.

Isolation: The communication port is electrically isolated from the backplane, with a withstand voltage of ≥ 2.5kV.

Diagnosis: Real time monitoring of communication links and port status, faults can be located at the channel level.

Response time: Communication delay ≤ 1ms, meeting the requirements of high-speed safety interlocking.

Environment: Working temperature -20 ℃~+60 ℃, protection level IP20, DIN rail installation.

Function and System Characteristics

Secure Communication: Implement secure data transmission between the controller and remote I/O modules, and support redundant communication.

Data exchange: Secure data exchange with upper level systems such as DCS and PLC, supporting SOE event recording.

Hot swappable: supports online replacement and maintains uninterrupted safe system operation.

Time synchronization: Supports SNTP protocol to ensure system time consistency.

Compatibility: Compatible with HIMatrix controllers such as F35 and F60, and compatible with F32/F33 series I/O modules.

Typical application scenarios

Petrochemical industry: ESD emergency shutdown system, SIS safety instrument system, reactor interlock.

Oil and gas energy: safety control of long-distance pipelines, safety communication of offshore platforms, and flare systems.

Power industry: boiler protection, turbine overspeed shutdown, generator safety control.

Manufacturing industry: robot safety doors, production line emergency stops, high-speed packaging machine safety communication.
