MVI71-DFNT以太网通信模块

1.产 品 资 料 介 绍：

MVI71‑DFNT 以太网通信模块 产品应用领域

一、离散制造业

1. 汽车整车与零部件产线：对接机器人、焊接设备、涂胶工作站、扭矩检测设备，实现生产节拍协同与数据追溯。
2. 电子装配与 SMT 产线：连接 AOI 光学检测机、SPI 锡膏检测设备、贴标机、物料防错系统，完成质量数据实时上传。
3. 包装与食品加工：对接称重配料系统、膜包机、装箱机、输送线控制系统，实现配方管理与批次追溯。
4. 机械加工中心：连接数控铣床 / 车床、刀具监控设备、在线测量仪器，实现加工数据采集与设备联网。

二、过程工业（流程行业）

5. 石油天然气：对接井口 RTU、计量撬、流量计、压力 / 温度变送器，实现油气田远程监控与数据采集。
6. 电力行业：连接继电保护装置、测控终端、电能表、环网柜，满足变电站监控与远动需求。
7. 化工与制药：接入 DCS 系统、pH/ORP 计、液位计、反应釜控制系统，实现工艺参数实时监控与联动控制。
8. 水处理与环保：对接水质在线分析仪、加药泵、泵站、污泥脱水设备，完成水厂 / 污水厂自动化运行。
9. 冶金与建材：连接炉温控制系统、轧机仪表、原料称重设备、窑炉控制器，保障连续生产稳定。

三、物流与仓储自动化

10. 智能立体仓库：对接堆垛机、AGV 小车、立体货架控制系统、扫码识别设备，实现仓储高效作业。
11. 港口与码头：连接岸桥、场桥、皮带秤、集装箱终端设备，完成装卸数据实时采集与传输。

四、基础设施与特殊场景

12. 轨道交通：对接车站信号系统、闸机、乘客信息显示终端、环境监测设备，保障车站运行安全。
13. 智能建筑：连接楼宇自控系统、电梯监控、能耗计量仪表、安防设备，实现建筑智能化管理。
14. 老旧设备升级改造：将 legacy PLC‑5 设备接入 EtherNet/IP 网络，实现系统升级与数据共享，降低改造成本。
15. 远程监控与维护：通过模块的透传通道，实现远程 PLC 程序下载、调试与故障诊断，提升维护效率。

MVI71-DFNT以太网通信模块  英文资料：

MVI71-DFNT Ethernet Communication Module Product Application Fields

MVI71-DFNT is an EtherNet/IP communication module designed by ProSoft specifically for Rockwell PLC-5 (1771 rack), which enables transparent interconnection between PLC-5 and EtherNet/IP network devices. It also supports DF1 over Ethernet and remote programming. The following are the core application areas:

1、 Discrete manufacturing industry

Automobile whole vehicle and component production line: docking robots, welding equipment, glue workstation, torque detection equipment, to achieve production cycle coordination and data traceability.

Electronic assembly and SMT production line: Connect AOI optical inspection machine, SPI solder paste inspection equipment, labeling machine, material error prevention system, and complete real-time uploading of quality data.

Packaging and food processing: Integrate weighing and ingredient systems, film packaging machines, packing machines, and conveyor control systems to achieve formula management and batch traceability.

Mechanical machining center: connects CNC milling machines/lathes, tool monitoring equipment, and online measuring instruments to achieve machining data collection and equipment networking.

2、 Process Industry (Process Industry)

Oil and gas: Connect wellhead RTUs, metering levers, flow meters, pressure/temperature transmitters to achieve remote monitoring and data acquisition of oil and gas fields.

Power industry: Connect relay protection devices, measurement and control terminals, energy meters, and ring main units to meet the monitoring and remote control needs of substations.

Chemical and Pharmaceutical: Connected to DCS system, pH/ORP meter, liquid level meter, and reactor control system to achieve real-time monitoring and linkage control of process parameters.

Water treatment and environmental protection: Integrate water quality online analyzers, dosing pumps, pumping stations, and sludge dewatering equipment to achieve automated operation of water plants/sewage treatment plants.

Metallurgy and Building Materials: Connect furnace temperature control systems, rolling mill instruments, raw material weighing equipment, and kiln controllers to ensure continuous and stable production.

3、 Logistics and Warehouse Automation

Intelligent three-dimensional warehouse: docking with stacker cranes, AGV carts, three-dimensional shelf control systems, and scanning recognition equipment to achieve efficient warehousing operations.

Port and Terminal: Connect shore bridges, yard bridges, belt scales, and container terminal equipment to complete real-time collection and transmission of loading and unloading data.

4、 Infrastructure and Special Scenarios

Rail transit: Integrate station signal systems, turnstiles, passenger information display terminals, and environmental monitoring equipment to ensure the safe operation of stations.

Intelligent Building: Connecting building automation systems, elevator monitoring, energy consumption meters, and security equipment to achieve intelligent management of buildings.

Upgrading and renovating old equipment: Connect legacy PLC-5 devices to EtherNet/IP networks to achieve system upgrades and data sharing, reducing renovation costs.

Remote monitoring and maintenance: Through the transparent transmission channel of the module, remote PLC program download, debugging, and fault diagnosis can be achieved to improve maintenance efficiency.

MVI71-DFNT以太网通信模块   产品展示

产品视频
