MVI94-GSC通讯模块

1.产 品 资 料 介 绍：

MVI94-GSC 通用串口通信模块

一、核心产品特点

1. 适配 Flex I/O 平台，单槽位安装，支持本地 / 远程机架部署
2. 1 路独立可配置串口（RS‑232/422/485 可选），支持全双工 / 半双工通信
3. 波特率 110–115200bps，数据位 5–8 位，奇偶校验 / 停止位可自定义
4. 支持流模式、终止字符、超时、数据包大小等灵活配置
5. 接收缓存最大 4096 字符，单次发送最大 10 字符，满足数据采集需求
6. 与 Flex I/O 处理器异步通信，不占用主扫描周期
7. 提供标准梯形图示例与 AOI，简化 PLC 程序集成
8. 独立 CFG 配置端口，支持在线调试与参数下载
9. LED 状态指示灯，快速诊断模块、串口与通信状态
10. 硬件电气隔离，提升工业现场抗干扰能力
11. 工业级宽温（-40℃～70℃）、抗振、抗冲击设计
12. 支持 RTS/CTS、XON/XOFF 等多种握手方式
13. 可模拟终端端口，对接老式串口终端与 HMI
14. 支持数据透明传输，兼容各类 ASCII 协议设备
15. 适用于 Flex I/O 系统的老旧设备改造与数据采集场景

二、典型应用领域

• 离散制造：对接条码扫描器、RFID、喷码机、贴标机、称重仪表，实现生产数据采集与追溯
• 物流仓储：连接电子标签拣选、AGV 调度终端、立体仓库设备
• 过程工业：接入流量计、压力 / 液位变送器、水质分析仪、阀门控制器
• 老旧设备升级：将 RS‑232/485 仪表、PLC、HMI 接入 Flex I/O 系统
• 通用数据采集：作为串口网关，对接非标 ASCII 设备、终端、打印机

MVI94-GSC通讯模块  英文资料：

MVI94-GSC Universal Serial Communication Module

MVI94-GSC is a universal ASCII serial communication module designed by ProSoft specifically for the Rockwell Flex I/O platform. It is used to connect various RS-232/422/485 serial devices to the Flex I/O system, achieving transparent data exchange.

1、 Core product features

Compatible with Flex I/O platform, single slot installation, supports local/remote rack deployment

1 independent configurable serial port (RS-232/422/485 optional), supporting full duplex/half duplex communication

Baud rate 110-115200bps, data bits 5-8, parity/stop bits customizable

Support flexible configuration of stream mode, termination character, timeout, packet size, etc

The maximum receiving cache is 4096 characters, and the maximum single transmission is 10 characters, meeting the data collection requirements

Asynchronous communication with Flex I/O processors without occupying the main scanning cycle

Provide standard ladder diagram examples and AOI to simplify PLC program integration

Independent CFG configuration port, supporting online debugging and parameter download

LED status indicator light for quick diagnosis of module, serial port, and communication status

Hardware electrical isolation enhances the anti-interference capability of industrial sites

Industrial grade wide temperature range (-40 ℃~70 ℃), anti vibration and anti impact design

Support multiple handshake methods such as RTS/CTS, XON/XOFF, etc

Can simulate terminal ports and interface with old-fashioned serial port terminals and HMI

Supports transparent data transmission and is compatible with various ASCII protocol devices

Suitable for the renovation of old equipment and data acquisition scenarios in Flex I/O systems

2、 Typical application areas

Discrete manufacturing: docking barcode scanners RFID、 Spray coding machine, labeling machine, weighing instrument, realize production data collection and traceability

Logistics warehousing: connecting electronic tag picking, AGV scheduling terminals, and three-dimensional warehouse equipment

Process industry: access to flow meters, pressure/level transmitters, water quality analyzers, valve controllers

Upgrading old equipment: Connecting RS-232/485 instruments, PLC, HMI to Flex I/O system

Universal data collection: As a serial gateway, it interfaces with non-standard ASCII devices, terminals, and printers

MVI94-GSC通讯模块   产品展示
