MVI46-DFNT以太网通信模块

1.产 品 资 料 介 绍：

MVI46-DFNT 以太网通信模块

核心特点

1. 单槽位设计，直接安装在 SLC 500 机架上
2. 10/100M 以太网接口，通信稳定高速
3. 支持 EtherNet/IP 客户端和服务器双模式
4. 可主动读写网络中其他 PLC 及设备数据
5. 支持多台上位机、HMI 同时连接访问
6. 提供以太网远程上传、下载程序功能
7. 自带独立数据缓冲区，不占用 PLC 大量资源
8. 通信参数可灵活配置，适配多种现场网络
9. 工业级设计，抗干扰强，适合工厂环境
10. 配置简单，调试方便，兼容性好

典型应用领域

1. SLC 500 PLC 接入 EtherNet/IP 工业以太网
2. 与 ControlLogix、MicroLogix 等 PLC 数据互通
3. HMI、SCADA 系统对 SLC PLC 进行监控
4. 老旧设备改造，实现以太网联网升级
5. 多台 PLC 组网，实现产线数据共享与联动控制
6. 远程监控、远程程序更新与设备维护

MVI46-DFNT以太网通信模块  英文资料：

MVI46-DFNT Ethernet Communication Module

MVI46-DFNT is an EtherNet/IP communication module designed by ProSoft for Rockwell SLC 500 PLC. It is used to connect SLC systems to industrial Ethernet, enabling device networking and data exchange.

Core Features

Single slot design, directly installed on SLC 500 rack

10/100M Ethernet interface, stable and high-speed communication

Supports dual mode of EtherNet/IP client and server

Can actively read and write data from other PLCs and devices in the network

Support simultaneous connection and access of multiple upper computers and HMIs

Provide Ethernet remote upload and download program functions

Equipped with an independent data buffer, it does not consume a large amount of PLC resources

Communication parameters can be flexibly configured to adapt to various on-site networks

Industrial grade design, strong anti-interference, suitable for factory environment

Simple configuration, easy debugging, and good compatibility

Typical application areas

SLC 500 PLC connected to EtherNet/IP industrial Ethernet

Interworking with PLC data such as ControlLogix and MicroLogix

HMI and SCADA systems monitor SLC PLC

Renovation of old equipment to achieve Ethernet networking upgrade

Multiple PLCs networked to achieve data sharing and linkage control on the production line

Remote monitoring, remote program updates, and equipment maintenance

This module effectively extends the Ethernet communication capability of SLC 500 PLC, enabling old systems to quickly connect to industrial Ethernet and meet the requirements of automated production line networking, data acquisition, and remote management.

MVI46-DFNT以太网通信模块   产品展示

产品视频
