MVI46-GEC通信接口模块

1.产 品 资 料 介 绍：

MVI46-GEC 通信接口模块

核心特点

1. 单槽位兼容 SLC 500 机架，本地 / 扩展机架均可安装
2. 1 个 10/100Mbps RJ45 以太网口，基于 TCP/IP 协议通信
3. 支持 客户端 / 服务器 双模式，可主动发起或被动接收连接
4. 内置 5000 字寄存器数据库，实现 PLC 与 ASCII 设备数据交换
5. 独立通信处理，不占用 SLC 主处理器资源，保障系统实时性
6. 支持自定义 ASCII 报文格式，适配各类非标 ASCII 设备
7. 提供 RS‑232 配置端口，用于本地参数配置与状态诊断
8. 工业级宽温设计（0–60℃），抗干扰强，适配恶劣工业现场
9. 与 RSLogix 500 无缝集成，通过梯形逻辑直接访问模块数据
10. 支持多连接并发，可同时对接多台 ASCII 设备
11. 提供配置软件与示例程序，简化部署与调试
12. 支持数据转发与协议转换，实现不同 ASCII 设备间互联互通
13. 兼容 SLC 5/02 及以上处理器，适配老旧系统升级
14. 背板电流 800mA @ 5VDC，低功耗设计
15. 支持故障诊断与状态反馈，便于系统维护

典型应用

1. SLC PLC 与条码扫描器、称重仪表等 ASCII 设备联网
2. 接入老旧 ASCII 协议设备，实现数据采集与远程监控
3. 与打印机、终端设备等进行以太网数据传输
4. 非标设备改造，通过以太网实现 PLC 与 ASCII 设备通信
5. 多站点分布式系统，通过 TCP/IP 网络实现 ASCII 数据共享
6. 工业现场传感器、执行器等 ASCII 设备的远程控制

MVI46-GEC通信接口模块  英文资料：

MVI46-GEC Communication Interface Module

MVI46-GEC is a universal ASCII Ethernet communication module designed by ProSoft specifically for Rockwell SLC 500 series PLCs. It is used to connect SLC systems to TCP/IP networks and achieve transparent data exchange with various ASCII protocol devices.

Core Features

Single slot compatible with SLC 500 rack, both local and expansion racks can be installed

1 10/100Mbps RJ45 Ethernet port, communication based on TCP/IP protocol

Supports client/server dual-mode, can initiate or passively receive connections

Built in 5000 word register database for data exchange between PLC and ASCII devices

Independent communication processing, does not occupy SLC main processor resources, ensuring system real-time performance

Support custom ASCII message format and adapt to various non-standard ASCII devices

Provide RS-232 configuration port for local parameter configuration and status diagnosis

Industrial grade wide temperature design (0-60 ℃), strong anti-interference, suitable for harsh industrial sites

Seamless integration with RSLogix 500, direct access to module data through ladder logic

Supports multiple concurrent connections and can simultaneously interface with multiple ASCII devices

Provide configuration software and sample programs to simplify deployment and debugging

Support data forwarding and protocol conversion to achieve interconnectivity between different ASCII devices

Compatible with SLC 5/02 and above processors, suitable for upgrading old systems

Backboard current 800mA @ 5VDC, low-power design

Support fault diagnosis and status feedback for easy system maintenance

Typical Applications

SLC PLC is networked with ASCII devices such as barcode scanners and weighing instruments

Connect old ASCII protocol devices to achieve data collection and remote monitoring

Ethernet data transmission with printers, terminal devices, etc

Non standard equipment modification, achieving communication between PLC and ASCII devices through Ethernet

Multi site distributed system, implementing ASCII data sharing through TCP/IP network

Remote control of ASCII devices such as sensors and actuators in industrial sites

This module provides flexible and universal ASCII Ethernet communication capabilities for SLC systems, quickly connecting the network links between PLCs and various ASCII devices, meeting the networking and data exchange needs of non-standard equipment in industrial sites.

MVI46-GEC通信接口模块   产品展示
