MVI46-GSC以太网扩展模块

1.产 品 资 料 介 绍：

MVI46-GSC 通用串行通信模块

核心特点

1. 单槽位安装，兼容 SLC 500 本地 / 扩展机架，不占用 PLC 原生串口
2. 提供 2 个独立可编程串行端口（PRT1/PRT2），支持 RS‑232/422/485 电气接口
3. 波特率范围 110–115200bps，数据位 5–8 位，奇偶校验 / 停止位可配置
4. 单端口最大支持 4096 字符 ASCII 字符串收发，适配长报文设备
5. 支持多种报文终止模式：流模式、终止字符、超时、包长限制
6. 支持硬件（RTS/CTS、DTR/DSR）与软件（XON/XOFF）流控
7. 独立通信处理，通过 SLC 背板 M0/M1 文件与 PLC 交换数据，不占用主处理器资源
8. 内置 RJ45 型 RS‑232 配置端口（CFG），用于本地参数设置与诊断
9. 多状态 LED 指示灯：模块状态、背板通信、串口活动、故障状态一目了然
10. 工业级设计，工作温度 0–60℃，抗干扰强，适配恶劣工业现场
11. 背板功耗 800mA @ 5VDC，低功耗，兼容 SLC 5/02 及以上处理器
12. 提供配置软件与梯形逻辑示例，简化部署与调试
13. 支持主 / 从模式，可主动发起或被动响应通信，适配双向数据交互场景
14. 支持自定义报文格式，兼容各类非标 ASCII 设备
15. 支持数据转发，实现 PLC 与多台串行设备的透明通信

典型应用

1. SLC PLC 与条码扫描器、称重仪表、RFID 阅读器等 ASCII 设备联网
2. 接入老旧串行协议设备，实现数据采集与远程监控
3. 对接打印机、字符终端、文本显示器，实现数据输出与操作交互
4. 非标设备改造，通过串行链路实现 PLC 与专用设备通信
5. 多站点分布式系统，通过 RS‑485 总线实现 ASCII 数据共享
6. 工业现场传感器、执行器等串行设备的远程控制与状态反馈

MVI46-GSC以太网扩展模块  英文资料：

MVI46-GSC Universal Serial Communication Module

MVI46-GSC is a universal ASCII serial communication module designed by ProSoft specifically for Rockwell SLC 500 series PLCs. It is used to expand independent serial communication ports for SLC systems and interface with various ASCII protocol devices.

Core Features

Single slot installation, compatible with SLC 500 local/expansion rack, does not occupy PLC native serial port

Provide 2 independent programmable serial ports (PRT1/PRT2), supporting RS-232/422/485 electrical interfaces

The baud rate range is 110-115200bps, with 5-8 data bits and configurable parity/stop bits

Single port supports up to 4096 character ASCII string transmission and reception, suitable for long message devices

Support multiple message termination modes: stream mode, termination character, timeout, packet length limit

Support hardware (RTS/CTS, DTR/DSR) and software (XON/XOFF) flow control

Independent communication processing, exchanging data with PLC through SLC backplane M0/M1 files without occupying main processor resources

Built in RJ45 RS-232 configuration port (CFG) for local parameter setting and diagnosis

Multi state LED indicator lights: module status, backplane communication, serial port activity, and fault status are clear at a glance

Industrial grade design, working temperature 0-60 ℃, strong anti-interference, suitable for harsh industrial sites

Backplane power consumption 800mA @ 5VDC, low power consumption, compatible with SLC 5/02 and above processors

Provide configuration software and ladder logic examples to simplify deployment and debugging

Supports master/slave mode, can actively initiate or passively respond to communication, adapted to bidirectional data interaction scenarios

Support custom message formats, compatible with various non-standard ASCII devices

Support data forwarding and achieve transparent communication between PLC and multiple serial devices

Typical Applications

SLC PLC is networked with ASCII devices such as barcode scanners, weighing instruments, RFID readers, etc

Connect old serial protocol devices to achieve data collection and remote monitoring

Docking with printers, character terminals, and text displays to achieve data output and operational interaction

Non standard equipment modification, achieving communication between PLC and specialized equipment through serial links

Multi site distributed system, implementing ASCII data sharing through RS-485 bus

Remote control and status feedback of serial devices such as sensors and actuators in industrial sites

This module provides flexible and independent serial communication expansion capabilities for SLC systems, quickly connecting PLC with various ASCII serial devices, and meeting the networking and data exchange needs of non-standard equipment in industrial sites.

MVI46-GSC以太网扩展模块   产品展示
