1.产 品 资 料 介 绍：

15 条核心特点

1. 双端口 Modbus Plus 网络：提供 2 个独立 MB+ 端口，支持冗余组网与多网段接入。
2. 主 / 从双模式：可配置为 Modbus Plus 主站或从站，灵活组网。
3. SLC 单槽兼容：标准 SLC 500 机架单槽安装，背板供电 800mA@5V DC。
4. 高速通信：固定 57.6kbps 波特率，100Kbps 级数据吞吐。
5. 4000 字数据区：模块内置 4000 字寄存器，与 SLC 处理器异步数据交换。
6. 全局数据（Global Data）：支持全局输入 / 输出各 32 字，实现节点间快速数据共享。
7. 路由层级支持：兼容 Modbus Plus 5 级路由，适配复杂网络架构。
8. 节点地址 1–64：软件配置节点地址，满足多站点组网。
9. 主站命令队列：最多支持 100 条主站轮询命令，自动执行数据采集。
10. 完整功能码集：从站支持 1/2/3/4/5/6/15/16；主站支持 3/16 功能码。
11. LED 状态诊断：电源、运行、端口活动、故障等多组 LED，快速定位问题。
12. 工业级可靠性：工作温度 0–60°C，存储 -40–85°C，抗 30g 冲击。
13. RSLogix 500 配置：通过 ProSoft 配置软件或梯形图参数化，提供示例程序。
14. 数据格式灵活：支持 16 位整数、32 位浮点格式。
15. 固件在线升级：通过配置口更新固件，无需拆机。

结尾

MVI46-MBP 通信卡  英文资料：

MVI46-MBP is a Modbus Plus dual port communication module designed by ProSoft specifically for Rockwell SLC series PLCs, which enables high-speed peer-to-peer interconnection between SLC and Modbus Plus devices such as Modicon PLCs, inverters, and instruments.

15 core characteristics

Dual port Modbus Plus network: Provides 2 independent MB+ports, supporting redundant networking and multi segment access.

Master/Slave Dual Mode: Can be configured as a Modbus Plus master or slave for flexible networking.

SLC single slot compatibility: Standard SLC 500 rack single slot installation, backplane power supply 800mA@5V  DC。

High speed communication: Fixed 57.6kbps baud rate, 100Kbps level data throughput.

4000 word data area: The module has a built-in 4000 word register for asynchronous data exchange with SLC processors.

Global Data: Supports global input/output of 32 characters each, enabling fast data sharing between nodes.

Routing hierarchy support: compatible with Modbus Plus 5-level routing, suitable for complex network architectures.

Node address 1-64: Software configuration node address, suitable for multi site networking.

Main station command queue: Supports up to 100 main station polling commands and automatically performs data collection.

Complete feature code set: Slave supports 1/2/3/4/5/6/15/16; The main station supports 3/16 function codes.

LED status diagnosis: Multiple sets of LEDs for power, operation, port activity, faults, etc., to quickly locate problems.

Industrial grade reliability: Operating temperature 0-60 ° C, storage -40-85 ° C, resistance to 30g impact.

RSLogix 500 configuration: Provide sample programs through ProSoft configuration software or ladder diagram parameterization.

Flexible data format: Supports 16 bit integer and 32-bit floating-point formats.

Firmware online upgrade: ｕｐｄａｔｅ firmware through the configuration port without disassembling the device.

ending

MVI46-MBP is a standard solution for SLC access to Modbus Plus networks, widely used for multi vendor equipment integration in industries such as manufacturing, power, and oil and gas.
