MVI46-3964r通信接口模块

MVI46-3964r通信接口模块

1.产 品 资 料 介 绍：

1. 双独立通信端口，支持 RS-232/422/485 三种接口模式。
2. 支持西门子 3964R 协议，可设置为主站或从站模式。
3. 支持 RK512 通信协议，可实现数据块读写功能。
4. 单槽位设计，直接适配 SLC 500 系列 PLC 机架。
5. 通过 M0/M1 数据区与 PLC 处理器进行数据交换。
6. 可通过梯形图程序实现数据收发与状态控制。
7. 波特率范围宽，支持多种现场设备通信速率。
8. 串口参数可灵活配置，满足不同设备对接要求。
9. 支持最大 512 字节单帧数据传输。
10. 配备独立配置端口，方便参数设置与调试。
11. 多组 LED 状态指示灯，便于现场运行诊断。
12. 工业级硬件设计，适应恶劣工业环境。
13. 采用背板供电，无需外接电源。
14. 支持配置文件快速导入，简化调试流程。
15. 支持固件在线升级，便于后期维护。

结尾

MVI46-3964r通信接口模块  英文资料：

MVI46-3964R is a 3964R/RK512 communication interface module designed by ProSoft for Allen Bradley SLC series PLCs, used for interconnection with Siemens equipment.

Dual independent communication ports, supporting three interface modes: RS-232/422/485.

Supports Siemens 3964R protocol and can be set to master or slave mode.

Supports RK512 communication protocol and can achieve data block read and write functions.

Single slot design, directly compatible with SLC 500 series PLC rack.

Exchange data with PLC processor through M0/M1 data area.

Data transmission and state control can be achieved through ladder diagram programs.

Wide baud rate range, supporting multiple on-site device communication rates.

The serial port parameters can be flexibly configured to meet the docking requirements of different devices.

Supports maximum single frame data transmission of 512 bytes.

Equipped with independent configuration ports for convenient parameter setting and debugging.

Multiple sets of LED status indicator lights for easy on-site operation and diagnosis.

Industrial grade hardware design, suitable for harsh industrial environments.

Powered by a backplane, no external power supply is required.

Support quick import of configuration files to simplify the debugging process.

Support firmware online upgrade for easy maintenance in the future.

ending

MVI46-3964R has strong stability and good compatibility, and is a commonly used communication module for SLC PLC to connect to Siemens 3964R/RK512 equipment.

MVI46-3964r通信接口模块  产品展示

产品视频
