MVI56-ADMNET服务器通信模块

MVI56-ADMNET服务器通信模块

1.产 品 资 料 介 绍：

1. 单槽位设计，直接兼容 ControlLogix 1756 机架，支持本地与扩展机架安装
2. 自带 1 路 10/100M 自适应以太网口，支持 TCP/IP、Socket 通信与自定义服务器协议
3. 配备 2 路完全光电隔离串行口，支持 RS‑232/422/485 硬件切换
4. 支持用户 C 语言编程开发，可实现私有协议、非标报文解析与定制通信逻辑
5. 提供以太网、串口、背板通信 API 函数库，简化开发与对接
6. 大容量内部数据缓冲区，灵活与 PLC 控制器进行双向数据交互
7. 串口波特率、数据位、校验位、停止位等参数可软件灵活配置
8. 支持自定义心跳、超时重传、校验算法，提升通信稳定性
9. 可作为 TCP 服务器 / 客户端，对接上位机、SCADA、数据库等系统
10. 支持多连接并行处理，同时与多台设备或服务器通信
11. 多组 LED 状态指示灯，实时显示模块运行、网络、串口与背板状态
12. 工业级硬件设计，抗干扰强，适应恶劣工业现场环境
13. 背板直接供电，无需外接电源，布线简洁
14. 支持配置文件下载与在线调试，方便开发与现场维护
15. 支持固件在线升级，持续扩展功能与兼容新设备

结尾

MVI56-ADMNET服务器通信模块  英文资料：

MVI56-ADMNET is a C language programmable Ethernet server communication module developed by ProSoft for the Allen Bradley ControlLogix platform. It is used to customize protocols, interface non-standard devices with server data.

Single slot design, directly compatible with ControlLogix 1756 rack, supports local and expansion rack installation

Comes with one 10/100M adaptive Ethernet port, supporting TCP/IP, Socket communication, and custom server protocols

Equipped with 2 fully optically isolated serial ports, supporting RS-232/422/485 hardware switching

Support user C language programming and development, capable of implementing private protocols, non-standard message parsing, and customized communication logic

Provide API libraries for Ethernet, serial port, and backplane communication to simplify development and integration

Large capacity internal data buffer for flexible bidirectional data exchange with PLC controller

The parameters of serial port baud rate, data bits, parity bits, stop bits, etc. can be flexibly configured by software

Support custom heartbeat, timeout retransmission, and verification algorithms to improve communication stability

Can be used as a TCP server/client to interface with upper computers SCADA、 Database and other systems

Support parallel processing with multiple connections and communicate with multiple devices or servers simultaneously

Multiple sets of LED status indicator lights, real-time display of module operation, network, serial port, and backplane status

Industrial grade hardware design, strong anti-interference ability, suitable for harsh industrial site environments

Backboard direct power supply, no need for external power supply, simple wiring

Support configuration file download and online debugging, convenient for development and on-site maintenance

Support firmware online upgrade, continuous expansion of functions and compatibility with new devices

ending

MVI56-ADMNET is suitable for non-standard communication, private protocol docking, industrial data upload to servers, and other scenarios. It is a highly flexible customized communication module for the ControlLogix system.

MVI56-ADMNET服务器通信模块  产品展示
