TRICONEX AI3351S2分析输入模块
1.产 品 资 料 介 绍：
- 产品型号：AI3351S2
- 模块类型：工业级模拟输入（Analog Input, AI）模块，专注于过程信号的高精度采集与处理
- 输入信号兼容性：支持多类工业标准模拟信号接入（具体信号类型可根据实际应用配置选择），包括 4–20 mA 电流信号（适用于压力、流量等变送器）、0–10 V 电压信号（适用于部分液位、温度传感器）、热电偶信号（如 K 型、J 型，用于高温环境温度检测）、RTD（电阻式温度检测器，如 Pt100，用于高精度温度测量）等
- 信号处理通道：采用多通道并行设计，可同时独立接收并处理多组模拟信号（通道数量根据具体型号配置确定），各通道间无干扰，满足多参数同步监测需求
- 信号采集分辨率：搭载高精度 A/D（模数）转换芯片，转换分辨率达 16 位及以上，能精准捕捉模拟信号的微小变化，确保信号处理的准确性与数据可信度，避免因分辨率不足导致的监测误差
- 电气隔离设计：输入通道与系统背板总线之间采用电气隔离技术（通常为光电隔离或电磁隔离），有效阻断外部干扰信号通过总线传入模块核心电路，同时防止模块内部故障对系统其他部件造成影响，显著提升抗电磁干扰能力与运行稳定性
- 数据通信方式：通过 Triconex 系统专用背板总线与 Tricon 控制器核心处理单元实现高速数据交互，通信延迟低，确保采集的信号能快速传输至控制器进行逻辑运算与控制决策
- 安全保护机制：集成多重保护功能，包括过流保护（防止输入电流过大烧毁通道）、通道隔离保护（单一通道故障不影响其他通道运行）、信号自诊断（实时监测信号是否正常，如开路、短路、超量程等），全方位保障模块与系统安全
英文资料：
1、 Product Overview
The TRICONEX AI3351S2 analysis input module is a high-precision analog signal processing unit focused on process industry safety and control scenarios, designed specifically to ensure the safety monitoring and stable control of critical industrial processes. Its core function is to accurately receive analog signals output by various on-site sensors (such as temperature sensors, pressure transmitters, flow meters, liquid level detectors, etc.), and complete filtering, conversion, and verification through built-in signal processing mechanisms, providing reliable data support for subsequent control decisions. This module relies heavily on the core architecture of Triconex's safety and fault-tolerant control system, which not only has industrial grade high reliability, but also incorporates redundancy design concepts to effectively resist single point failure risks. Therefore, it is widely used in industries with strict safety and stability requirements, such as oil and gas extraction and transportation, chemical reaction processes, power production scheduling, and pharmaceutical compliance production. It has become a core signal access component in critical safety control circuits and real-time monitoring systems.
2、 Core technical parameters (typical characteristics)
Product model: AI3351S2
Module type: Industrial grade Analog Input (AI) module, focusing on high-precision acquisition and processing of process signals
Input signal compatibility: Supports multiple types of industrial standard analog signal access (specific signal types can be selected according to actual application configurations), including 4-20 mA current signals (applicable to pressure, flow, and other transmitters), 0-10 V voltage signals (applicable to some liquid level and temperature sensors), thermocouple signals (such as K and J types, used for high temperature environment temperature detection), RTD (resistance temperature detector, such as Pt100, used for high-precision temperature measurement), etc
Signal processing channel: Adopting a multi-channel parallel design, it can independently receive and process multiple sets of analog signals at the same time (the number of channels is determined according to the specific model configuration), with no interference between each channel, meeting the requirements of multi parameter synchronous monitoring
Signal acquisition resolution: Equipped with a high-precision A/D (Analog to Digital) conversion chip, the conversion resolution reaches 16 bits or more, which can accurately capture small changes in analog signals, ensure the accuracy of signal processing and data reliability, and avoid monitoring errors caused by insufficient resolution
Electrical isolation design: Electrical isolation technology (usually photoelectric isolation or electromagnetic isolation) is used between the input channel and the system backplane bus to effectively block external interference signals from entering the module core circuit through the bus, while preventing internal module faults from affecting other components of the system, significantly improving the ability to resist electromagnetic interference and operational stability
Data communication method: High speed data exchange is achieved through the dedicated backplane bus of the Triconex system and the core processing unit of the Tricon controller, with low communication delay, ensuring that the collected signals can be quickly transmitted to the controller for logical operations and control decisions
Security protection mechanism: integrates multiple protection functions, including overcurrent protection, channel isolation protection, signal self diagnosis (real-time monitoring of whether the signal is normal, such as open circuit, short circuit, overtravel, etc.), to comprehensively ensure the safety of the module and system
