TRICONEX RO3451 控制器模块

TRICONEX RO3451 控制器模块

1.产 品 资 料 介 绍：

中文资料：

型号：TRICONEX RO3451
类型：数字输出控制模块（Relay Output Module）

产品概述

TRICONEX RO3451 是 Tricon 安全控制系统中的继电器输出模块，用于将控制信号通过继电器触点形式传递至现场设备，适用于控制需要电气隔离的负载设备，如接触器、指示灯、警报器、继电器等。

该模块支持三重冗余配置，符合安全仪表系统（SIS）的高完整性要求，是 Tricon 系统中重要的安全输出模块之一。

模块功能

• 提供 32 路独立继电器输出通道

• 将数字控制信号转换为继电器触点输出

• 输出信号具备电气隔离，保护系统稳定运行

• 用于现场设备的控制与驱动

• 支持冗余架构同步工作，提升系统可用性

技术规格

• 输出通道数量：32 点继电器输出

• 继电器类型：Form A 单刀单掷（SPST-NO）干接点输出

• 触点额定容量：

  • 最大电压：30 VDC / 250 VAC

  • 最大电流：2 A（阻性负载）

• 通道隔离：每个通道与系统电隔离

• 响应时间：约 10 毫秒以内

• 输出状态显示：前面板具备每通道 LED 状态指示灯

• 模块冗余：三通道独立驱动、投票输出机制，确保输出可靠性

• 安装结构：插拔式模块，配合专用底座使用

• 热插拔支持：模块支持在线更换，无需系统下电

产品特点

• 三重冗余安全架构：每通道由三个独立驱动器控制，满足 SIL 3 要求

• 输出保护：具备通道故障检测、继电器卡滞检测功能

• 工业级设计：抗电磁干扰、高抗震性能、宽工作温度范围

• 维护便利：LED 状态显示与诊断信息便于快速定位故障

• 与系统兼容性强：可无缝集成至 Tricon 主控系统中

英文资料：

Model: TRICONEX RO3451

Type: Relay Output Module

product overview

TRICONEX RO3451 is a relay output module in the Tricon safety control system, used to transmit control signals to field devices through relay contacts. It is suitable for controlling load devices that require electrical isolation, such as contactors, indicator lights, alarms, relays, etc.

This module supports triple redundancy configuration and meets the high integrity requirements of Safety Instrumented Systems (SIS). It is one of the important safety output modules in the Tricon system.

Module functionality

Provide 32 independent relay output channels

Convert digital control signals into relay contact outputs

The output signal has electrical isolation to protect the stable operation of the system

Used for controlling and driving on-site equipment

Support redundant architecture synchronization work to improve system availability

technical specifications

Number of output channels: 32 relay outputs

Relay type: Form A Single pole Single throw (SPST-NO) dry contact output

Rated contact capacity:

Maximum voltage: 30 VDC/250 VAC

Maximum current: 2 A (resistive load)

Channel isolation: Each channel is electrically isolated from the system

Response time: within approximately 10 milliseconds

Output status display: The front panel has LED status indicators for each channel

Module redundancy: Three channel independent drive and voting output mechanism to ensure output reliability

Installation structure: Plug in module, used in conjunction with a dedicated base

Hot swappable support: Modules can be replaced online without the need for system power off

Product Features

Triple redundant safety architecture: Each channel is controlled by three independent drivers, meeting SIL 3 requirements

Output protection: equipped with channel fault detection and relay jamming detection functions

Industrial grade design: anti electromagnetic interference, high seismic performance, wide working temperature range

Easy maintenance: LED status display and diagnostic information facilitate quick fault location

Strong compatibility with the system: can be seamlessly integrated into the Tricon main control system
