TRICONEX DI3301 数字输入模块

TRICONEX  DI3301 数字输入模块

1.产 品 资 料 介 绍：

中文资料：

型号：TRICONEX DI3301
类型：数字输入模块（Digital Input Module）

产品简介

TRICONEX DI3301 是一款高可靠性的数字输入模块，设计用于 Triconex 三重冗余安全系统。它主要负责采集现场开关量信号，并提供三重化容错架构下的安全数据采集功能，广泛应用于对安全性要求极高的工业环境。

核心功能

• 接收来自现场设备的数字信号（如干触点、限位开关、继电器输出等）

• 将信号输入至 Tricon 控制器的冗余处理系统

• 提供信号滤波、隔离、防抖等功能，提高信号质量

• 支持与其他 I/O 模块同步运行，实现安全控制逻辑

技术规格（典型参数，可能略有差异，具体以型号版本为准）

• 输入通道数量：32 个独立数字输入通道

• 输入电压范围：18–32 VDC（典型 24VDC）

• 输入电流：每通道最大 6 mA

• 输入类型：干接点或湿接点信号输入

• 通道隔离：各输入通道与系统总线隔离

• 冗余设计：每通道支持 TMR（三重冗余）输入路径

• 响应时间：≤ 5 ms（含滤波）

• 诊断功能：支持线路监测、断线检测、短路检测等

• 工作温度：-20°C ~ +60°C

• 存储温度：-40°C ~ +85°C

• 湿度范围：5%–95% RH，无冷凝

英文资料：

Model: TRICONEX DI3301

Type: Digital Input Module

Product Introduction

Triconex DI3301 is a highly reliable digital input module designed for use in Triconex triple redundant safety systems. It is mainly responsible for collecting on-site switch signals and providing safety data acquisition function under a triple fault-tolerant architecture, widely used in industrial environments with extremely high safety requirements.

Core functions

Receive digital signals from on-site devices (such as dry contacts, limit switches, relay outputs, etc.)

Input the signal into the redundant processing system of the Tricon controller

Provide signal filtering, isolation, anti shake and other functions to improve signal quality

Support synchronous operation with other I/O modules to achieve safety control logic

Technical specifications (typical parameters, may vary slightly, please refer to the model version for details)

Number of input channels: 32 independent digital input channels

Input voltage range: 18-32 VDC (typical 24VDC)

Input current: Maximum 6 mA per channel

Input type: dry contact or wet contact signal input

Channel isolation: Each input channel is isolated from the system bus

Redundant design: Each channel supports TMR (Triple Redundancy) input path

Response time: ≤ 5 ms (including filtering)

Diagnostic function: supports line monitoring, disconnection detection, short circuit detection, etc

Working temperature: -20 ° C~+60 ° C

Storage temperature: -40 ° C~+85 ° C

Humidity range: 5% -95% RH, no condensation
