OADM 20I6572/S14F传感器

OADM 20I6572/S14F传感器

1.产 品 资 料 介 绍：

1. 品牌为瑞士 Baumer 堡盟，属于 OADM 系列激光测距传感器。
2. 测量量程 50mm 至 300mm，适配短距离高精度测量需求。
3. 光源采用脉冲式红色激光二极管，波长 650nm，激光等级 2 类。
4. 测量分辨率高达 4μm，线性精度 ±0.25mm，测量精度极高。
5. 响应与释放时间均小于 0.9ms，满足高速动态检测场景。
6. 输出信号为双模拟量：4-20mA 电流与 0-10V 电压，兼容主流控制系统。
7. 配备 1 路 PNP 报警输出，可反馈异常与故障状态。
8. 供电电压 12-28V DC，最大功耗 100mA，适配工业直流电源。
9. 接口为 8 针可旋转 M12 连接器，安装布线灵活。
10. 支持按键与外部两种自学习校准方式，调试便捷。
11. 防护等级 IP67，防尘防水，适应多粉尘、潮湿工业环境。
12. 工作温度 0°C 至 + 50°C，具备温度补偿，温漂小于 0.03%/K。
13. 具备短路、反接极性双重电气保护，模块稳定性强。
14. 双 LED 指示灯：绿色显示通电，红色提示镜头污染或故障。
15. 广泛用于精密定位、厚度测量、电子元件检测、自动化生产线等领域。

OADM 20I6572/S14F传感器   英文资料：

OADM 20I6572/S14F is a high-precision laser ranging sensor from Baumer Platz, Switzerland. It focuses on analog output and short-range precision measurement, and is suitable for high-precision positioning, thickness detection, and displacement measurement scenarios in industrial automation.

The brand is Baumer, Switzerland, and belongs to the OADM series of laser ranging sensors.

Measuring range of 50mm to 300mm, suitable for short distance high-precision measurement requirements.

The light source adopts a pulsed red laser diode with a wavelength of 650nm and a laser level of Class 2.

The measurement resolution is as high as 4 μ m, with a linear accuracy of ± 0.25mm, and the measurement accuracy is extremely high.

The response and release time are both less than 0.9ms, which meets the requirements of high-speed dynamic detection scenarios.

The output signal is a dual-mode analog: 4-20mA current and 0-10V voltage, compatible with mainstream control systems.

Equipped with 1 PNP alarm output, it can provide feedback on abnormal and fault states.

Supply voltage 12-28V DC, maximum power consumption 100mA, suitable for industrial DC power supply.

The interface is an 8-pin rotatable M12 connector, with flexible installation and wiring.

Supports both button and external self-learning calibration methods, making debugging convenient.

Protection level IP67, dustproof and waterproof, suitable for industrial environments with high dust and humidity.

The working temperature ranges from 0 ° C to+50 ° C, with temperature compensation and a temperature drift of less than 0.03%/K.

Equipped with dual electrical protection for short circuit and reverse polarity, the module has strong stability.

Dual LED indicator lights: green indicates power on, red indicates lens contamination or malfunction.

Widely used in precision positioning, thickness measurement, electronic component testing, automated production lines and other fields.

OADM 20I6572/S14F has become the core sensor for precision detection and high-precision displacement control scenarios due to its ultra-high measurement accuracy, fast response, stable analog output, and reliable industrial protection.

OADM 20I6572/S14F传感器  产品展示

产品视频
