1.产 品 资 料 介 绍：

1. 归属系统：艾默生 DeltaV M 系列 / S 系列 DCS 专用 I/O 模块，型号 KJ3003X1-BA1，物料号 12P0914X042/062/072。
2. 端口规格：2 路独立串行通信端口，端口间及与系统侧电气隔离。
3. 接口类型：支持 RS-232、RS-422/485 半双工、RS-422/485 全双工三种模式。
4. 通信协议：原生支持 Modbus RTU/ASCII，兼容第三方串口协议（如 DF1、ASCII）。
5. 波特率：300–115200 bps，多档可选，适配不同设备速率。
6. 数据格式：7/8 位数据位，1/2 位停止位，奇 / 偶 / 无校验。
7. 冗余能力：支持冗余配对，关键应用可实现无扰切换。
8. 供电：DeltaV 总线 12VDC 供电，无需额外电源。
9. 安装：标准 DIN 导轨安装，支持热插拔，在线维护。
10. 诊断：模块级 + 端口级诊断，支持通信故障、断线、超时报警。
11. 环境：工作温度 - 40℃~+70℃，湿度 5%–95% 无凝露，抗振动 / 冲击。
12. 认证：CE、FCC、ATEX 等，适用于危险工业区域。
13. 配置：通过 DeltaV Explorer/AMS 组态端口、协议、超时、重试参数。
14. 应用：连接 PLC、仪表、变频器、智能阀门等串口设备。
15. 优势：隔离可靠、协议灵活、冗余可用，适配石化、电力、冶金等场景。

结尾

KJ3003X1-BA1串行接口模块 英文资料：

KJ3003X1-BA1 is a dedicated serial interface module for Emerson DeltaV DCS systems, used to achieve reliable communication between the system and Modbus, third-party serial devices, and supports multi protocol, multi port isolation, and redundant configuration.

Belonging system: Emerson DeltaV M series/S series DCS dedicated I/O module, model KJ3003X1-BA1, material number 12P0914X042/062/072.

Port specifications: 2 independent serial communication ports, electrically isolated between ports and from the system side.

Interface type: Supports RS-232, RS-422/485 half duplex, and RS-422/485 full duplex modes.

Communication protocol: Native support for Modbus RTU/ASCII, compatible with third-party serial protocols such as DF1 and ASCII.

Baud rate: 300-115200 bps, available in multiple settings, suitable for different device speeds.

Data format: 7/8-bit data bits, 1/2 stop bits, odd/even/no checksum.

Redundancy capability: Supports redundant pairing, enabling undisturbed switching for critical applications.

Power supply: DeltaV bus 12VDC power supply, no additional power supply required.

Installation: Standard DIN rail installation, supports hot swapping, online maintenance.

Diagnosis: Module level+port level diagnosis, supporting communication failure, disconnection, timeout alarm.

Environment: Working temperature -40 ℃~+70 ℃, humidity 5% -95%, no condensation, resistant to vibration/impact.

Certification: CE, FCC, ATEX, etc., suitable for hazardous industrial areas.

Configuration: Configure ports, protocols, timeouts, and retry parameters through DeltaV Explorer/AMS.

Application: Connect serial devices such as PLC, instruments, frequency converters, intelligent valves, etc.

Advantages: Reliable isolation, flexible protocol, redundant availability, suitable for petrochemical, power, metallurgical and other scenarios.

ending

KJ3003X1-BA1 is designed with stable isolation, multi protocol compatibility, and redundancy, becoming the core communication module for DeltaV system to interface with third-party serial devices, ensuring reliable and efficient industrial data exchange.
