KJ3005X1-BA1传感器

KJ3005X1-BA1传感器

1.产 品 资 料 介 绍：

1. 系统归属：艾默生 DeltaV M 系列专用 I/O 模块，型号 KJ3005X1-BA1，物料号 12P1866X042/12P2047X022。
2. 接口类型：AS-i（Actuator-Sensor Interface）主站接口，兼容 AS-i 2.1/3.0 标准。
3. 通道能力：单模块支持最多31 个 AS-i 从站，可接入 62 个数字量输入 / 输出点位。
4. 通信速率：标准167 kbps，总线最长可达 100 米（不加中继）。
5. 供电方式：DeltaV 本地总线 12VDC 供电，无需额外电源。
6. 电气隔离：模块与 AS-i 总线侧电气隔离，提升抗干扰与安全性。
7. 安装方式：标准 DIN 导轨安装，支持热插拔，在线维护便捷。
8. 诊断功能：模块级 + 从站级双重诊断，支持从站掉线、短路、通信异常报警。
9. 环境适应：工作温度 - 40℃~+70℃，湿度 5%–95% 无凝露，抗振动 / 冲击。
10. 防爆认证：符合 ATEX、IECEx 等危险区域认证，可用于易燃易爆场所。
11. 组态配置：通过 DeltaV Explorer 软件完成 AS-i 从站扫描、地址分配与点位映射。
12. 应用场景：连接现场按钮、接近开关、光电传感器、电磁阀、指示灯等 AS-i 设备。
13. 优势特点：布线简化、成本低、扩展灵活、响应快，适合离散与流程工业现场。
14. 兼容系统：适配 DeltaV M 系列控制器，支持与其他 I/O 模块混合部署。
15. 典型行业：汽车制造、食品饮料、包装、物流、化工、电力等现场传感器 / 执行器密集场景。

结尾

KJ3005X1-BA1传感器  英文资料：

KJ3005X1-BA1 is an AS-i (actuator sensor interface) communication module specifically designed for Emerson DeltaV DCS systems. It is used to connect on-site AS-i bus sensors/actuators, enabling low-cost and highly reliable distributed I/O access.

System ownership: Emerson DeltaV M series dedicated I/O module, model KJ3005X1-BA1, material number 12P1866X042/12P2047X022.

Interface type: AS-i (Actor Sensor Interface) main station interface, compatible with AS-i 2.1/3.0 standards.

Channel capability: A single module supports up to 31 AS-i slave stations and can access 62 digital input/output points.

Communication speed: standard 167 kbps, bus length up to 100 meters (without relay).

Power supply method: DeltaV local bus 12VDC power supply, no additional power supply required.

Electrical isolation: The module is electrically isolated from the AS-i bus side to enhance anti-interference and safety.

Installation method: Standard DIN rail installation, supports hot swapping, and easy online maintenance.

Diagnostic function: Dual diagnosis at module level and slave level, supporting alarms for slave disconnection, short circuit, and communication abnormalities.

Environmental adaptation: Working temperature -40 ℃~+70 ℃, humidity 5% -95%, no condensation, anti vibration/impact.

Explosion proof certification: Complies with ATEX, IECEx and other hazardous area certifications, and can be used in flammable and explosive places.

Configuration: AS-i slave scanning, address allocation, and point mapping are completed through DeltaV Explorer software.

Application scenario: Connect AS-i devices such as on-site buttons, proximity switches, photoelectric sensors, solenoid valves, indicator lights, etc.

Advantages and features: Simplified wiring, low cost, flexible expansion, fast response, suitable for discrete and process industry sites.

Compatible system: Compatible with DeltaV M-series controllers and supports mixed deployment with other I/O modules.

Typical industries: automotive manufacturing, food and beverage, packaging, logistics, chemical industry, power and other on-site sensor/actuator intensive scenarios.

ending

KJ3005X1-BA1 has become the preferred module for connecting field sensors/actuators in DeltaV systems with the efficient access capability of AS-i bus, improved diagnosis and industrial grade reliability, greatly simplifying field wiring and system integration.

KJ3005X1-BA1传感器  产品展示

产品视频
