KJ3007X1-EA1端子块

KJ3007X1-EA1端子块

1.产 品 资 料 介 绍：

1. 品牌与型号：艾默生（Emerson）DeltaV 专用，型号 KJ3007X1-EA1，物料号 12P2413X032。
2. 适配模块：与 KJ3007X1-BA1 Profibus DP 主站模块配对使用。
3. 接口类型：Profibus DP 总线接线端子，支持 RS-485 差分信号接入。
4. 电气规格：额定电压 5VDC，最大电流 100mA，总线侧电气隔离。
5. 接线能力：提供 Profibus A/B 线、屏蔽地、终端电阻等专用接线位。
6. 终端配置：内置可插拔终端电阻（120Ω），适配总线首尾端匹配。
7. 保护设计：集成过压、浪涌抑制，提升总线抗干扰能力。
8. 安装方式：标准 DIN 导轨安装，与主站模块直插式连接。
9. 环境参数：工作温度 0℃~60℃，湿度 5%~95% 无凝露，IP20 防护。
10. 机械性能：抗冲击 10g（11ms 半正弦），抗振动 0.5g（16~150Hz）。
11. 防爆认证：ATEX II 3G、FM Class I Div 2，可用于危险区域。
12. 材质与寿命：铜质触点 + 绝缘壳体，接触电阻低，工业级长寿命。
13. 诊断支持：配合主站模块实现总线断线、短路、通信异常诊断。
14. 应用场景：石化、电力、冶金等行业 Profibus DP 现场总线接入。
15. 核心价值：规范接线、隔离保护、简化 Profibus 总线部署与维护。

结尾

KJ3007X1-EA1端子块  英文资料：

KJ3007X1-EA1 is a specialized Profibus DP communication terminal block for Emerson DeltaV system, designed to be matched with KJ3007X1-BA1 Profibus DP master station module, achieving reliable wiring, isolation and protection of on-site Profibus bus.

Brand and model: Emerson DeltaV specific, model KJ3007X1-EA1, material number 12P2413X032.

Adaptation module: Paired with KJ3007X1-BA1 Profibus DP master station module for use.

Interface type: Profibus DP bus terminal block, supporting RS-485 differential signal access.

Electrical specifications: Rated voltage 5VDC, maximum current 100mA, bus side electrical isolation.

Wiring capability: Provides dedicated wiring positions for Profibus A/B lines, shielding ground, terminal resistors, etc.

Terminal configuration: Built in pluggable terminal resistor (120 Ω), compatible with both ends of the bus.

Protection design: Integrated overvoltage and surge suppression to enhance bus anti-interference capability.

Installation method: Standard DIN rail installation, with direct insertion connection to the main station module.

Environmental parameters: working temperature of 0 ℃~60 ℃, humidity of 5%~95%, no condensation, IP20 protection.

Mechanical performance: shock resistance of 10g (11ms half sine), vibration resistance of 0.5g (16~150Hz).

Explosion proof certification: ATEX II 3G, FM Class I Div 2, suitable for use in hazardous areas.

Material and lifespan: Copper contacts+insulated housing, low contact resistance, industrial grade long lifespan.

Diagnostic support: Cooperate with the main station module to achieve diagnosis of bus disconnection, short circuit, and communication abnormalities.

Application scenarios: Profibus DP fieldbus access in industries such as petrochemicals, power, metallurgy, etc.

Core values: Standardized wiring, isolation protection, simplified deployment and maintenance of Profibus bus.

ending

KJ3007X1-EA1, as a dedicated wiring terminal for Profibus DP bus, is a key accessory for fieldbus access, ensuring reliable isolation, complete protection, and industrial grade adaptation to ensure stable Profibus communication in DeltaV system.
