1.产 品 资 料 介 绍：

1. 型号与归属：艾默生 DeltaV M 系列专用 SOE 模块，型号 KJ3008X1-BA1，物料号 12P2293X052。
2. 核心功能：事件顺序记录（SOE），毫秒级时间戳，精准记录开关量跳变顺序与时刻。
3. 通道规格：16 路独立数字量输入，支持干接点 / 24VDC 有源信号，通道间电气隔离。
4. 时间精度：1ms 分辨率，系统同步时间戳，满足工业事故追忆精度要求。
5. 事件缓存：内置大容量缓存，可存储数千条事件，掉电不丢失。
6. 供电方式：DeltaV 本地总线 12VDC 供电（75mA），现场侧 24VDC 辅助供电。
7. 输入特性：单通道 5mA@24VDC，支持干接点 / 有源 24VDC，滤波可组态。
8. 通信机制：通过 DeltaV I/O 总线上传事件，与控制器时间同步。
9. 冗余支持：支持冗余配置，关键场景无扰切换，提升可用性。
10. 安装方式：标准 DIN 导轨安装，支持热插拔，在线维护。
11. 诊断功能：模块级 + 通道级诊断，支持断线、短路、通信异常报警。
12. 环境参数：工作温度 0℃~60℃，湿度 5%–95% 无凝露，抗振动 / 冲击。
13. 防爆认证：ATEX、FM 等，适用于 Class I Div 2 危险区域。
14. 组态配置：DeltaV Explorer 组态通道、滤波、事件触发方式与上传策略。
15. 典型应用：石化、电力、冶金等行业的事故追忆、联锁动作记录、合规审计场景。

结尾

KJ3008X1-BA1逻辑控制器模块  英文资料：

KJ3008X1-BA1 is an Emerson DeltaV DCS specific SOE (sequence of events recording) module (non logic controller) used for millisecond level precise capture, recording, and reporting of on-site switch events, meeting the requirements of accident recall and compliance tracing.

Model and ownership: Emerson DeltaV M series dedicated SOE module, model KJ3008X1-BA1, material number 12P2293X052.

Core function: Sequence of Events (SOE) recording, millisecond level timestamp, accurate recording of switch jumping sequence and time.

Channel specifications: 16 independent digital inputs, supporting dry contacts/24VDC active signals, with electrical isolation between channels.

Time accuracy: 1ms resolution, system synchronized timestamp, meeting the accuracy requirements for industrial accident recall.

Event Cache: Built in high-capacity cache that can store thousands of events without losing them in case of power failure.

Power supply mode: DeltaV local bus 12VDC power supply (75mA), on-site side 24VDC auxiliary power supply.

Input feature: Single channel 5mA@24VDC Supports dry contacts/active 24VDC, with configurable filtering.

Communication mechanism: Upload events through DeltaV I/O bus and synchronize with controller time.

Redundancy support: Supports redundant configuration, seamless switching in critical scenarios, and improves availability.

Installation method: Standard DIN rail installation, supports hot plugging, online maintenance.

Diagnostic function: Module level+channel level diagnosis, supporting alarms for disconnection, short circuit, and communication abnormalities.

Environmental parameters: working temperature of 0 ℃~60 ℃, humidity of 5% -95%, no condensation, anti vibration/impact.

Explosion proof certification: ATEX, FM, etc., suitable for Class I Div 2 hazardous areas.

Configuration configuration: DeltaV Explorer configuration channels, filtering, event triggering methods, and upload strategies.

Typical applications: Accident recall, interlocking action recording, and compliance audit scenarios in industries such as petrochemicals, power, and metallurgy.

ending

KJ3008X1-BA1, with millisecond level time accuracy, high reliability isolation, and perfect event management, has become the core SOE module for DeltaV system to achieve precise accident recall and compliance traceability, ensuring industrial process safety and traceability.
