1C31129G02 阀门定位器

1C31129G02 阀门定位器

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation DCS 系统，为专用0–10VDC电压型模拟输出电子模块。
2. 搭配 1C31132G02 特性模块，组成完整 4 通道 0–10V 输出单元。
3. 4 路独立电压输出通道，单通道驱动能力适配主流阀门定位器与电动执行器。
4. 输出精度高，满量程误差≤±0.02%，保障阀门定位精准度。
5. 通道间 / 通道与背板1500VDC 电气隔离，强抗现场电磁干扰。
6. 支持热插拔，在线维护更换无需系统停机，提升运维效率。
7. 每路内置过压、过流保护，防止外部异常损坏模块与执行器。
8. 集成诊断功能，支持通道开路 / 短路检测、输出超限报警，故障信息上传系统。
9. 输出更新周期≤100ms，响应迅速，满足快速调节需求。
10. 适配 1B30035H01 等 Ovation 标准 I/O 底座，安装兼容性好。
11. 工业级宽温设计，工作温度 0℃–60℃，适应恶劣工况。
12. 支持系统冗余配置，可实现双模块热备，提高关键阀门控制可靠性。
13. 标准模块尺寸，结构紧凑，占用机柜空间小，便于系统扩容。
14. 专为驱动阀门定位器、电动调节阀、变频器、伺服机构设计，适配电压型执行机构。
15. 广泛应用于电厂、化工、冶金、水处理等行业，实现阀门开度、执行器行程精准控制。

1C31129G02 阀门定位器 英文资料：

1C31129G02 is an Emerson Ovation DCS dedicated 0-10VDC analog output electronic module, paired with the 1C31132G02 feature module, which outputs 4 channels of 0-10V voltage signals for driving valve positioners, electric actuators, frequency converters, etc. It is the core component of closed-loop control for voltage type actuators in the process industry.

Belonging to Emerson Ovation DCS system, it is a dedicated 0-10VDC voltage type analog output electronic module.

Combined with the 1C31132G02 feature module, form a complete 4-channel 0-10V output unit.

4 independent voltage output channels, single channel driving capability suitable for mainstream valve positioners and electric actuators.

High output accuracy, with a full-scale error of ≤± 0.02%, ensuring precise valve positioning.

Channel to channel/channel to backplane 1500VDC electrical isolation, strong resistance to on-site electromagnetic interference.

Support hot plugging, online maintenance and replacement without system shutdown, improving operation and maintenance efficiency.

Each channel is equipped with built-in overvoltage and overcurrent protection to prevent external abnormal damage to modules and actuators.

Integrated diagnostic function, supporting channel open/short circuit detection, output over limit alarm, and uploading fault information to the system.

Output ｕｐｄａｔｅ cycle ≤ 100ms, fast response, meeting the requirements of rapid adjustment.

Compatible with Ovation standard I/O bases such as 1B30035H01, with good installation compatibility.

Industrial grade wide temperature design, working temperature range of 0 ℃ -60 ℃, suitable for harsh working conditions.

Support system redundancy configuration, enable dual module hot backup, and improve the reliability of key valve control.

Standard module size, compact structure, small cabinet space occupation, and easy system expansion.

Specially designed for driving valve positioners, electric control valves, frequency converters, and servo mechanisms, compatible with voltage type actuators.

Widely used in industries such as power plants, chemicals, metallurgy, and water treatment to achieve precise control of valve opening and actuator stroke.

1C31129G02 阀门定位器  产品展示
