1C31147G01 脉冲累积器

1C31147G01 脉冲累积器

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation（原西屋）DCS 系统，为专用脉冲累积 / 频率输入模块。
2. 配置2 路独立脉冲输入通道，支持并行采集两路脉冲信号。
3. 兼容多电平脉冲输入：24/48V（CT/CT-，CE 认证）、12V 中速（MC/HM-）、5V 中速（HC/HM-）。
4. 采用32 位硬件计数器，支持超大脉冲累积量，无溢出风险。
5. 最高支持50kHz 脉冲频率，适配高速脉冲源（如涡轮流量计、编码器）。
6. 通道与系统侧电气隔离，抗现场电磁干扰，保护系统安全。
7. 支持脉冲累积、频率测量、周期测量三种工作模式，灵活适配不同应用。
8. 内置硬件滤波，抑制现场噪声，提升计数稳定性。
9. 支持热插拔，在线维护无需系统停机，降低运维影响。
10. 适配 Ovation 标准 I/O 底座（如 1B30035H01），安装兼容性强。
11. 工业级宽温设计，工作温度 - 20℃～+60℃，适应恶劣工况。
12. 累积精度达 **±0.1% 满量程 **，满足高精度计量需求。
13. 支持通道诊断（开路 / 短路 / 超限），故障信息实时上传系统。
14. 可与 Ovation 控制器无缝对接，数据直接参与控制逻辑与计量统计。
15. 广泛用于电厂、化工、冶金、油气、水处理等行业，实现脉冲信号的精准采集与累积。

1C31147G01 脉冲累积器 英文资料：

1C31147G01 is a dedicated dual channel pulse accumulation/frequency measurement module for Emerson Ovation DCS, used for high-speed pulse counting, speed/flow/frequency acquisition, and cumulative measurement. It is the core hardware for pulse signal acquisition in industrial processes.

Belonging to Emerson Ovation (formerly Westinghouse) DCS system, it is a dedicated pulse accumulation/frequency input module.

Configure 2 independent pulse input channels, supporting parallel acquisition of two pulse signals.

Compatible with multi-level pulse input: 24/48V (CT/CT -, CE certified), 12V medium speed (MC/HM -), 5V medium speed (HC/HM -).

Adopting a 32-bit hardware counter, supporting ultra large pulse accumulation without overflow risk.

Supports a maximum pulse frequency of 50kHz and is compatible with high-speed pulse sources such as turbine flow meters and encoders.

Channel and system side electrical isolation, resistant to on-site electromagnetic interference, protecting system safety.

Supports three working modes: pulse accumulation, frequency measurement, and cycle measurement, flexibly adapting to different applications.

Built in hardware filtering to suppress on-site noise and improve counting stability.

Support hot plugging, online maintenance does not require system shutdown, reducing the impact of operation and maintenance.

Compatible with Ovation standard I/O base (such as 1B30035H01), with strong installation compatibility.

Industrial grade wide temperature design, working temperature range of -20 ℃ to+60 ℃, suitable for harsh working conditions.

The cumulative accuracy reaches * * ± 0.1% of full scale * *, meeting the high-precision measurement requirements.

Support channel diagnosis (open circuit/short circuit/over limit), and real-time upload of fault information to the system.

It can seamlessly integrate with Ovation controllers, allowing data to directly participate in control logic and measurement statistics.

Widely used in industries such as power plants, chemicals, metallurgy, oil and gas, water treatment, etc., to achieve precise acquisition and accumulation of pulse signals.

1C31147G01 脉冲累积器  产品展示
