1C31161G02输入模块

1C31161G02输入模块

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation（原西屋）DCS 系统，为RTD 专用模拟输入电子模块，需搭配对应特性模块与标准 I/O 底座使用。
2. 配置8 路独立 RTD 输入通道，支持单通道独立组态，可并行采集 8 路温度信号，提升系统集成度。
3. 兼容主流 RTD 类型：PT100（2/3/4 线制）、PT1000，适配工业常用电阻温度传感器，接线灵活。
4. 支持2/3/4 线制接线，4 线制可消除引线电阻误差，3 线制适配现场常规布线，满足不同精度需求。
5. 测量精度达 **±0.1℃**（典型值），满量程误差≤±0.2%，分辨率 0.01℃，保障高精度温度采集。
6. 内置硬件级线性化与冷端补偿，无需软件额外校准，直接输出精准温度数值，简化组态。
7. 通道间、通道与系统背板1500VDC 电气隔离，抗电磁干扰能力强，适应工业强干扰环境。
8. 集成完善诊断功能，支持传感器开路 / 短路、测量超量程、模块内部故障检测，故障信息实时上传 Ovation 控制器。
9. 支持热插拔，在线更换模块无需系统停机，大幅降低运维对生产的影响，提升系统可用性。
10. 适配 Ovation 标准 I/O 底座（如 1B30035H01），模块化设计，安装与接线便捷，兼容本地 / 远程 I/O 部署。
11. 工业级宽温设计，工作温度0℃–60℃，存储温度 - 40℃–85℃，适应恶劣工业环境。
12. 每通道内置过压 / 过流保护，防止现场传感器短路或异常电压损坏模块，提升运行安全性。
13. 数据更新周期≤200ms，响应迅速，满足实时控制与快速联锁的时间要求。
14. 支持系统冗余配置，可与同型号模块组成热备，确保关键温度测点的连续监测，避免单点故障。
15. 广泛应用于火电 / 核电、化工 / 炼油、冶金、油气、水处理、制药等行业，用于锅炉壁温、管道介质、反应器、换热器等关键设备的温度测量与控制。

1C31161G02输入模块 英文资料：

1C31161G02 is an 8-channel RTD temperature input module dedicated to Emerson Ovation DCS. Its core is used to collect signals from resistance temperature sensors such as PT100/PT1000. Through high-precision signal conditioning and digital conversion, it provides reliable data for temperature monitoring, control, and interlocking in process industries. It is the core component for accurate measurement of high/medium temperatures in power plants, chemical industries, and other industries.

Belonging to Emerson Ovation (formerly Westinghouse) DCS system, it is an RTD specific analog input electronic module that needs to be used with corresponding characteristic modules and standard I/O bases.

Configure 8 independent RTD input channels, support single channel independent configuration, can collect 8 temperature signals in parallel, and improve system integration.

Compatible with mainstream RTD types: PT100 (2/3/4 wire system) PT1000， Suitable for commonly used resistance temperature sensors in industry, with flexible wiring.

Supports 2/3/4 wire system wiring, 4-wire system can eliminate lead resistance errors, and 3-wire system is suitable for on-site conventional wiring to meet different precision requirements.

The measurement accuracy reaches * * ± 0.1 ℃ * * (typical value), the full-scale error is ≤± 0.2%, and the resolution is 0.01 ℃, ensuring high-precision temperature acquisition.

Built in hardware level linearization and cold end compensation, no additional software calibration required, direct output of accurate temperature values, simplifying configuration.

1500VDC electrical isolation between channels and between channels and system backboards, with strong electromagnetic interference resistance, suitable for industrial strong interference environments.

Integrate and improve diagnostic functions, support sensor open/short circuit, measurement over range, module internal fault detection, and real-time upload of fault information to Ovation controller.

Support hot swapping, online module replacement without system shutdown, significantly reducing the impact of operation and maintenance on production and improving system availability.

Compatible with Ovation standard I/O base (such as 1B30035H01), modular design, easy installation and wiring, compatible with local/remote I/O deployment.

Industrial grade wide temperature design, working temperature range of 0 ℃ -60 ℃, storage temperature range of -40 ℃ -85 ℃, suitable for harsh industrial environments.

Each channel is equipped with built-in overvoltage/overcurrent protection to prevent on-site sensor short circuits or abnormal voltage damage to the module, enhancing operational safety.

The data ｕｐｄａｔｅ cycle is ≤ 200ms, with rapid response and meeting the time requirements for real-time control and fast interlocking.

Supporting system redundancy configuration, it can form a hot backup with modules of the same model to ensure continuous monitoring of key temperature measurement points and avoid single point failures.

Widely used in industries such as thermal power/nuclear power, chemical/refining, metallurgy, oil and gas, water treatment, pharmaceuticals, etc., for temperature measurement and control of key equipment such as boiler wall temperature, pipeline media, reactors, heat exchangers, etc.

1C31161G02输入模块  产品展示
