1C31164G02输入模块

 1C31164G02输入模块

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation DCS 系统，为RTD 输入专用特性模块，必须与 1C31161G02 电子模块配合，组成完整 8 通道 RTD 输入单元。
2. 专为CE 认证合规系统设计，满足欧盟工业安全与电磁兼容标准，适配出口或合规要求高的项目。
3. 提供8 通道独立 RTD 信号调理，与电子模块通道一一对应，支持单通道独立配置。
4. 兼容PT100/PT1000等工业标准 RTD 传感器，适配 2/3/4 线制接线，消除引线电阻误差。
5. 内置高精度冷端补偿电路，自动补偿环境温度对测量的影响，无需额外校准，保障全温区测量精度。
6. 实现通道间、现场与系统侧 1500VDC 电气隔离，符合 CE EMC 要求，强抗工业电磁干扰。
7. 集成信号滤波与线性化处理，将 RTD 电阻信号精准转换为标准数字量，直接供 Ovation 控制器读取。
8. 每通道内置过压 / 过流 / 反接保护，防止现场传感器故障损坏模块与系统。
9. 支持传感器开路 / 短路诊断，故障状态实时上传，便于快速定位与维护。
10. 适配 Ovation 标准 I/O 底座（如 1B30035H01），模块化设计，安装与接线便捷。
11. 工业级宽温设计，工作温度0℃–60℃，适应电厂、化工等严苛工况。
12. 支持热插拔，在线更换不影响系统运行，降低运维停机时间。
13. 与 1C31161G02 配对后，整体测量精度达 **±0.1℃**，分辨率 0.01℃，满足高精度温度监测需求。
14. 数据更新周期≤200ms，响应迅速，适配实时控制与联锁场景。
15. 广泛应用于火电 / 核电、化工、冶金、油气、水处理等行业，用于锅炉、反应器、换热器等关键设备的 CE 合规温度采集。

 1C31164G02输入模块 英文资料：

1C31164G02 is an 8-channel RTD temperature input characteristic module specifically designed for Emerson Ovation DCS, paired with the 1C31161G02 electronic module. It is specifically designed for CE certification compliance scenarios and is responsible for RTD signal conditioning, isolation, and cold end compensation. It is a key supporting component for high-precision temperature acquisition.

Belonging to the Emerson Ovation DCS system, it is a dedicated characteristic module for RTD input and must be combined with the 1C31161G02 electronic module to form a complete 8-channel RTD input unit.

Specially designed for CE certification compliance systems, meeting EU industrial safety and electromagnetic compatibility standards, suitable for projects with high export or compliance requirements.

Provide 8-channel independent RTD signal conditioning, corresponding one-to-one with electronic module channels, supporting single channel independent configuration.

Compatible with industrial standard RTD sensors such as PT100/PT1000, compatible with 2/3/4 wire connections, eliminating lead resistance errors.

Built in high-precision cold end compensation circuit, automatically compensates for the impact of environmental temperature on measurement, without the need for additional calibration, ensuring measurement accuracy throughout the entire temperature range.

Realize 1500VDC electrical isolation between channels, on-site and system side, in compliance with CE EMC requirements, and strong resistance to industrial electromagnetic interference.

Integrating signal filtering and linearization processing, accurately converting RTD resistance signals into standard digital quantities for direct reading by Ovation controllers.

Each channel is equipped with built-in overvoltage/overcurrent/reverse protection to prevent on-site sensor failures from damaging modules and systems.

Support sensor open/short circuit diagnosis, real-time uploading of fault status for quick positioning and maintenance.

Compatible with Ovation standard I/O base (such as 1B30035H01), modular design, easy installation and wiring.

Industrial grade wide temperature design, working temperature range of 0 ℃ -60 ℃, suitable for harsh working conditions such as power plants and chemical industries.

Support hot swapping, online replacement does not affect system operation, reducing maintenance downtime.

After pairing with 1C31161G02, the overall measurement accuracy reaches * * ± 0.1 ℃ * *, with a resolution of 0.01 ℃, meeting the requirements of high-precision temperature monitoring.

Data ｕｐｄａｔｅ cycle ≤ 200ms, fast response, suitable for real-time control and interlocking scenarios.

Widely used in industries such as thermal power/nuclear power, chemical, metallurgical, oil and gas, water treatment, etc., for CE compliant temperature collection of key equipment such as boilers, reactors, and heat exchangers.

 1C31164G02输入模块  产品展示
