1C31227G02分析输入(电压)模块

1C31227G02分析输入(电压)模块

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation DCS 系统，为模拟输入特性模块（PMOD），必须与 1C31125G02 电子模块配合，组成完整 8 通道模拟输入单元。
2. 配置8 路独立模拟输入通道，支持电压 / 电流双模式，单通道独立组态，并行采集多路高精度信号。
3. 兼容电压 / 电流双输入：电压支持 ±10V、0–5V、1–5V；电流支持 4–20mA、0–20mA，适配分析仪表、高精度变送器。
4. 内置24V DC 回路供电，支持两线制变送器直接接入，无需额外现场电源，简化布线。
5. 测量精度达 **±0.05% FS**，14 位分辨率，满足 pH、溶解氧、浓度等分析参数的高精度采集要求。
6. 通道间、通道与系统背板1500VDC 电气隔离，强抗电磁干扰，适配工业强干扰环境。
7. 集成硬件滤波与线性化处理，滤除现场噪声，将模拟信号精准转换为数字量，直接供 Ovation 控制器读取。
8. 每通道内置过压 / 过流 / 反接保护，防止传感器故障损坏模块与系统。
9. 支持传感器开路 / 短路 / 超量程诊断，故障状态实时上传，便于快速定位与维护。
10. 适配 Ovation 标准 I/O 底座（如 1B30035H01），模块化设计，安装与接线便捷。
11. 工业级宽温设计，工作温度 **-20℃～+60℃**，适应电厂、化工等严苛工况。
12. 支持热插拔，在线更换不影响系统运行，降低运维停机时间。
13. 数据更新周期≤100ms，响应迅速，适配实时分析与控制场景。
14. 支持系统冗余配置，可与同型号模块组成热备，确保关键分析测点连续监测。
15. 广泛应用于火电 / 核电、化工、水处理、制药、冶金等行业，用于 pH、ORP、电导率、溶解氧、浓度等分析仪表的信号采集与监测。

1C31227G02分析输入(电压)模块 英文资料：

1C31227G02 is an 8-channel high-precision voltage/current analog input characteristic module (PMOD) specifically designed for Emerson Ovation DCS. It needs to be paired with the 1C31125G02 electronic module (EMOD) to provide signal conditioning, isolation, and digital conversion for analytical instruments and high-precision transmitters. It is a core component for high-precision process monitoring in industries such as power plants and chemical engineering.

Belonging to the Emerson Ovation DCS system, it is an analog input characteristic module (PMOD) that must be combined with the 1C31125G02 electronic module to form a complete 8-channel analog input unit.

Configure 8 independent analog input channels, support voltage/current dual-mode, single channel independent configuration, parallel acquisition of multiple high-precision signals.

Compatible with voltage/current dual input: voltage supports ± 10V, 0-5V, 1-5V; Current support 4-20mA, 0-20mA, suitable for analytical instruments and high-precision transmitters.

Built in 24V DC circuit power supply, supporting direct connection of two-wire transmitters without the need for additional on-site power supply, simplifying wiring.

The measurement accuracy reaches * * ± 0.05% FS * *, with a 14 bit resolution, meeting the high-precision acquisition requirements for analysis parameters such as pH, dissolved oxygen, and concentration.

1500VDC electrical isolation between channels and between channels and system backboards, strong resistance to electromagnetic interference, suitable for industrial strong interference environments.

Integrate hardware filtering and linearization processing to filter out on-site noise, accurately convert analog signals into digital quantities, and directly read by Ovation controllers.

Each channel is equipped with built-in overvoltage/overcurrent/reverse protection to prevent sensor failures from damaging modules and systems.

Support sensor open circuit/short circuit/over range diagnosis, real-time upload of fault status for quick positioning and maintenance.

Compatible with Ovation standard I/O base (such as 1B30035H01), modular design, easy installation and wiring.

Industrial grade wide temperature design, working temperature range of * * -20 ℃~+60 ℃ * *, suitable for harsh working conditions such as power plants and chemical industries.

Support hot swapping, online replacement does not affect system operation, reducing maintenance downtime.

Data ｕｐｄａｔｅ cycle ≤ 100ms, fast response, suitable for real-time analysis and control scenarios.

Support system redundancy configuration, can form a hot backup with modules of the same model, ensuring continuous monitoring of key analysis measurement points.

Widely used in industries such as thermal power/nuclear power, chemical, water treatment, pharmaceuticals, metallurgy, etc., for signal acquisition and monitoring of pH, ORP, conductivity, dissolved oxygen, concentration and other analytical instruments.

1C31227G02分析输入(电压)模块  产品展示
