1.产 品 资 料 介 绍：
IC697ALG441 模拟输入扩展器模块 产品特点
- 专为 GE Fanuc 90-70 PLC 系统设计，是模拟量输入专用扩展模块
- 提供 16 路差分电压输入通道，采集稳定可靠
- 标准信号量程为 - 10V～+10V，适配各类电压型传感器
- 必须与 IC697ALG230 基础模块配合使用，构成完整采集系统
- 采用 12 位分辨率模数转换，满足工业控制精度要求
- 输入阻抗高，有效降低信号损耗，支持远距离信号采集
- 通道与系统背板之间具备电气隔离，抗干扰能力强
- 支持全软件组态配置，无需硬件跳线或拨码开关
- 内置过压保护与瞬态干扰保护，提升模块使用寿命
- 具备独立 LED 状态指示灯，方便查看运行与故障状态
- 支持在线热插拔功能，更换维护不影响系统正常运行
- 采用单槽紧凑型设计，节省机柜安装空间
- 宽温工作环境，抗振动、抗冲击，适应恶劣工业现场
- 支持多模块级联扩展，满足大规模模拟量采集需求
- 出厂校准数据存储于 EEPROM，长期稳定无需频繁校准
IC697ALG441模拟输入扩展器模块 英文资料：
IC697ALG441 Analog Input Expander Module Product Features
Specially designed for GE Fanuc 90-70 PLC system, it is an analog input dedicated expansion module
Provide 16 differential voltage input channels for stable and reliable data acquisition
The standard signal range is -10V to+10V, suitable for various voltage sensors
Must be used in conjunction with the IC697ALG230 basic module to form a complete acquisition system
Adopting 12 bit resolution analog-to-digital conversion to meet industrial control accuracy requirements
High input impedance effectively reduces signal loss and supports long-distance signal acquisition
There is electrical isolation between the channel and the system backplane, with strong anti-interference ability
Supports full software configuration without the need for hardware jumpers or dip switches
Built in overvoltage protection and transient interference protection to enhance module lifespan
Equipped with independent LED status indicator lights for easy viewing of operation and fault status
Support online hot plugging function, replacement and maintenance do not affect the normal operation of the system
Adopting a single slot compact design to save cabinet installation space
Wide temperature working environment, resistant to vibration and impact, suitable for harsh industrial sites
Support cascading expansion of multiple modules to meet the needs of large-scale analog data acquisition
The factory calibration data is stored in EEPROM, which is stable for a long time and does not require frequent calibration
IC697ALG441 is an ideal expansion module for centralized acquisition of voltage analog signals in large PLC systems, characterized by high density, high isolation, and high reliability.
IC697ALG441模拟输入扩展器模块 产品展示
