IC697BEM741总线控制器

1.产 品 资 料 介 绍：

IC697BEM741 FIP 总线控制器（15 条要点）

1. 专为 GE Fanuc 90-70 系列 PLC 设计，是FIP 现场总线专用双路总线控制器。
2. 提供2 路独立 FIP 总线通道，可同时管理两条 FIP 网络。
3. 支持扫描 IC693 FIP 远程 I/O 扫描器、IC670 FIP 模块及通用 FIP 设备。
4. 单模块占用 PLC 背板1 个标准插槽，兼容标准与 VME Integrator 背板。
5. 系统最多可配置4 个 BEM741，搭配其他总线控制器总数≤31 个。
6. 采用同步扫描机制，FIP 总线上 I/O 设备同时扫描，数据每周期上传 CPU 一次。
7. 全软件组态，通过 Logicmaster 90-70 等编程软件完成网络与设备配置。
8. 支持 FIP 总线主站控制，实现远程 I/O 与现场设备的集中管理。
9. 具备电气隔离特性，通道与 PLC 背板隔离，提升抗干扰能力。
10. 工业级防护，符合 Class I、Groups ABCD、Div 2 防爆标准，温度等级 T4A。
11. 内置故障诊断功能，通过 LED 指示灯快速定位总线与模块异常。
12. 支持热插拔，在线更换不影响系统正常运行。
13. 单通道可连接大量 FIP 从站，满足大规模分布式 I/O 扩展需求。
14. 背板供电（+5V），无需额外现场电源，安装部署简便。
15. 适配化工、电力、冶金等严苛工业环境，稳定可靠。

IC697BEM741总线控制器 英文资料：

IC697BEM741 FIP Bus Controller (15 Key Points)

Specially designed for GE Fanuc 90-70 series PLC, it is a dual bus controller dedicated to FIP fieldbus.

Provide 2 independent FIP bus channels, capable of managing two FIP networks simultaneously.

Supports scanning IC693 FIP remote I/O scanners, IC670 FIP modules, and general FIP devices.

A single module occupies one standard slot on the PLC backplane, compatible with both standard and VME integrator backplanes.

The system can be configured with up to 4 BEM741, with a total of ≤ 31 other bus controllers.

Adopting a synchronous scanning mechanism, I/O devices on the FIP bus are scanned simultaneously, and data is uploaded to the CPU once per cycle.

Full software configuration, complete network and device configuration through programming software such as Logicmaster 90-70.

Support FIP bus master control to achieve centralized management of remote I/O and on-site devices.

Equipped with electrical isolation characteristics, the channel is isolated from the PLC backplane to enhance anti-interference capability.

Industrial grade protection, compliant with Class I, Groups ABCD, Div 2 explosion-proof standards, temperature rating T4A.

Built in fault diagnosis function, quickly locate bus and module abnormalities through LED indicator lights.

Support hot swapping, online replacement does not affect the normal operation of the system.

A single channel can connect a large number of FIP slaves, meeting the needs of large-scale distributed I/O expansion.

Backboard power supply (+5V), no additional on-site power supply required, easy installation and deployment.

Suitable for harsh industrial environments such as chemical, power, metallurgy, etc., stable and reliable.

IC697BEM741总线控制器 产品展示

产品视频
