IC697CGR772处理器单元模块

1.产 品 资 料 介 绍：

IC697CGR772 处理器单元模块（15 条要点）

1. 专为 GE Fanuc 90-70 系列 PLC 设计，是热备冗余 + 双总线架构的高性能 CPU 模块。
2. 采用80486 DX4 96MHz处理器，支持 32 位浮点运算，单布尔指令执行仅0.4μs。
3. 单槽紧凑型设计，占用 90-70 背板1 个标准插槽，兼容标准与 VME Integrator 背板。
4. 内置512KB 电池备份 CMOS RAM，断电后程序与数据长期保存，配IC697ACC701 锂电池。
5. 支持热备冗余（Hot-Standby），实现无扰切换、CPU 同步、冗余通信，切换时间≤1 扫描周期。
6. 具备双总线架构，兼容 IC660/IC661 Genius 总线与 IC697 本地 I/O，混合 I/O 扩展能力强。
7. 最大 I/O 容量：2048DI+2048DO，模拟量 I/O 最高支持8000 点，适配大规模系统。
8. 提供3 个独立 SNP 串行端口（1×RS232、2×RS485），支持编程、监控与第三方设备通信。
9. 全软件组态，无硬件跳线 / 拨码，通过 Logicmaster 90-70 完成配置，操作便捷。
10. 内置电池备份实时时钟（RTC），时间戳精准，满足过程追溯与时序控制需求。
11. 配备7 个 LED 状态指示灯，实时显示运行、通信、故障、电池低电等状态，诊断直观。
12. 支持在线编程、在线维修，冗余系统可单模块维护，不中断生产运行。
13. 具备三级操作模式开关（运行 / 编程 / 保护）+ 密码 + 钥匙锁，三重数据安全防护。
14. 背板 **+5V供电，电流需求约1.3A**，无需额外电源，部署简洁。
15. 工业级宽温（-40℃~+85℃）、抗振设计，通过 Class I Div 2 防爆认证，适配严苛场景。

IC697CGR772处理器单元模块 英文资料：

IC697CGR772 processor unit module (15 key points)

Specially designed for GE Fanuc 90-70 series PLC, it is a high-performance CPU module with hot standby redundancy and dual bus architecture.

Using an 80486 DX4 96MHz processor, it supports 32-bit floating-point operations and can execute a single Boolean instruction in just 0.4 μ s.

Single slot compact design, occupying one standard slot on 90-70 backboards, compatible with standard and VME integrator backboards.

Built in 512KB battery backup CMOS RAM, long-term storage of programs and data after power failure, equipped with IC697ACC701 lithium battery.

Support hot standby redundancy, achieve interference free switching, CPU synchronization, redundant communication, with switching time ≤ 1 scan cycle.

Equipped with a dual bus architecture, compatible with IC660/IC661 Genius bus and IC697 local I/O, with strong hybrid I/O expansion capability.

Maximum I/O capacity: 2048 DI+2048 DO, analog I/O supports up to 8000 points, suitable for large-scale systems.

Provide 3 independent SNP serial ports (1 × RS232, 2 × RS485), supporting programming, monitoring, and communication with third-party devices.

Full software configuration, no hardware jumpers/dials, configured through Logicmaster 90-70, easy to operate.

Built in battery backup real-time clock (RTC), precise timestamp, meeting the needs of process traceability and timing control.

Equipped with 7 LED status indicator lights, real-time display of operation, communication, fault, low battery status, etc., providing intuitive diagnosis.

Support online programming and maintenance, redundant systems can be maintained with a single module without interrupting production operations.

Equipped with three-level operation mode switch (run/program/protect)+password+key lock, triple data security protection.

Backboard * *+5V power supply, current requirement of about 1.3A * *, no additional power supply required, simple deployment.

Industrial grade wide temperature range (-40 ℃~+85 ℃), anti vibration design, certified as Class I Div 2 explosion-proof, suitable for harsh environments.

IC697CGR772 is a highly reliable, redundant, and high-performance core CPU for the 90-70 system, and is the preferred control unit for continuous production industrial scenarios.
