1.产 品 资 料 介 绍：
一、核心定位与关键特性
- 类型与容量：CMOS 静态 RAM 扩展子板，提供64KB/128KB/256KB/512KB四种容量版本（标准为 256KB），可配置为程序或数据存储区。
- 适配对象：仅支持IC697PCM711 可编程协处理器、IC697CPU771/772 CPU 模块。
- 安装方式：作为 ** 子板（Daughter Board）** 直接安装在 PCM/CPU 模块内部插槽，与母板共用槽位，不额外占用机架空间。
- 掉电保持：依赖主板IC697ACC701 锂电池供电，断电后数据不丢失，电池寿命约 10 年。
- 数据校验：CPU 后台实时校验程序内存；PCM 在上电 / 复位时自动校验存储区，保障数据完整性。
- 兼容性：与 Series 90-70 标准机架、背板及编程软件（Logicmaster 90、Proficy Machine Edition）完全兼容。
二、技术规格
- 所属系列：GE Fanuc Series 90-70
- 存储类型：CMOS SRAM
- 容量版本：64KB/128KB/256KB/512KB
- 工作电压：由母板（PCM/CPU）供电，无需外部电源
- 掉电保持：主板锂电池供电，数据永久保持
- 安装位置：PCM/CPU 模块内部子板插槽
- 环境温度：0–60℃（工业标准）
- 错误校验：CPU 后台实时校验；PCM 上电 / 复位校验
三、功能与应用场景
- 大容量程序存储：满足 PCM 的 MegaBasic 程序、复杂逻辑、多任务控制对内存的高需求。
- 海量数据存储：用于保存过程数据、配方参数、历史记录、报警信息等非易失性数据。
- 协处理器增强：为 PCM711 的数据采集、处理、通信任务提供充足内存空间。
- 典型应用：汽车制造、冶金、电力、水处理、物料搬运、包装机械等中大型 PLC 控制系统。
IC697MEM717可编程复合处理器 英文资料：
IC697MEM717 is a CMOS SRAM expansion storage board for GE Fanuc Series 90-70 series, specifically designed to provide large capacity program and data memory expansion for IC697PCM711 programmable co processor (PCM) and IC697CP771/772, without occupying additional rack slots. Data is retained by the motherboard battery during power outages.
1、 Core positioning and key characteristics
Type and Capacity: CMOS Static RAM Expansion Board, available in four capacity versions: 64KB/128KB/256KB/512KB (standard is 256KB), configurable as a program or data storage area.
Adaptation object: Only supports IC697PCM711 programmable co processor and IC697CP771/772 CPU module.
Installation method: As a * * Daughter Board * *, it is directly installed in the internal slot of the PCM/CPU module, sharing the slot with the motherboard, without occupying additional rack space.
Power outage maintenance: relying on the IC697ACC701 lithium battery on the motherboard for power supply, data will not be lost after power outage, and the battery life is about 10 years.
Data verification: Real time CPU backend verification of program memory; PCM automatically verifies the storage area during power on/reset to ensure data integrity.
Compatibility: Fully compatible with Series 90-70 standard rack, backplane, and programming software (Logicmaster 90, Proficy Machine Edition).
2、 Technical specifications
Series: GE Fanuc Series 90-70
Storage type: CMOS SRAM
Capacity version: 64KB/128KB/256KB/512KB
Working voltage: Powered by the motherboard (PCM/CPU), no external power supply required
Power down maintenance: The motherboard is powered by a lithium battery, and data is permanently retained
Installation position: Internal motherboard slot of PCM/CPU module
Environmental temperature: 0-60 ℃ (industrial standard)
Error verification: Real time CPU backend verification; PCM power on/reset verification
3、 Function and application scenarios
Large capacity program storage: meets the high memory requirements of PCM MegaBasic programs, complex logic, and multitasking control.
Massive data storage: used to store non-volatile data such as process data, formula parameters, historical records, alarm information, etc.
Co processor enhancement: Provides sufficient memory space for data acquisition, processing, and communication tasks of PCM711.
Typical applications: Large scale PLC control systems in automotive manufacturing, metallurgy, power, water treatment, material handling, packaging machinery, and other industries.
IC697MEM717可编程复合处理器 产品展示
