HE693STP104AX处理器模块

1.产 品 资 料 介 绍：

HE693STP104AX 处理器模块 产品特点

1. 原厂专用定位：GE Fanuc 原装正品，Series 90-30 PLC 系统专属运动控制模块，系统兼容性强，无缝对接整机控制。
2. 高速步进控制：最高245kHz脉冲输出速率，支持微步驱动适配，定位精准、运行平滑，满足高速精密定位需求。
3. 可编程多模式：支持点位控制、连续运动、回零、直线插补等多种运动模式，可编程适配简单直线到复杂多轴联动。
4. 丰富外设接口：可直接连接步进驱动器、限位开关、编码器反馈，支持闭环位置校正，提升定位精度与稳定性。
5. 独立轴控设计：单轴独立运动处理器，不占用 PLC 主 CPU 资源，保障主控制与运动控制双向高效并行。
6. 宽温工业级：工作温度 **-20℃~70℃**，湿度 0%~95% 无凝露，适应高低温、潮湿、粉尘等严苛工业现场。
7. 紧凑标准结构：符合 90-30 系列机架规格，体积小巧、重量轻（约 0.2kg），节省柜内空间，支持密集安装。
8. 强抗干扰能力：EMC 优化设计，抗电磁干扰、防浪涌，可与变频器、伺服等设备共柜稳定运行。
9. 优质硬件选材：军工级 PCB、镀金触点、工业级芯片，抗氧化、耐磨损，机械与电气寿命超长。
10. 多重保护机制：内置过流、短路、过压、过热保护，防止模块与外接电机、驱动器损坏。
11. 灵活供电规格：支持 24V DC 标准供电，内置电源滤波与反接保护，适配工业现场常规电源。
12. 简易编程调试：支持 GE 编程软件参数化配置，支持状态监控、在线修改、故障诊断，降低调试难度。
13. 智能故障诊断：实时监测脉冲输出、位置偏差、通信状态，异常即时报警输出，快速定位故障。
14. 国际权威认证：通过 CE、UL、CSA 认证，符合全球工业安全标准，可出口全球各地区。
15. 全场景覆盖：广泛应用于数控机床、包装机械、纺织设备、电子制造、机器人、自动化生产线等精密运动控制领域。

HE693STP104AX处理器模块    产品英文

HE693STP104AX processor module product features

HE693STP104AX is a GE Fanuc 90-30 series dedicated stepper motion control module, featuring high-precision positioning, high-speed pulse output, strong adaptability, and stable reliability. It is designed specifically for industrial single axis/multi axis precision motion control scenarios and is widely used in fields such as machine tools, packaging, textiles, and automation production lines.

Original factory exclusive positioning: GE Fanuc genuine product, Series 90-30 PLC system exclusive motion control module, strong system compatibility, seamless integration with the whole machine control.

High speed step control: With a maximum pulse output rate of 245kHz, it supports micro step drive adaptation, precise positioning, smooth operation, and meets the requirements of high-speed precision positioning.

Programmable multi-mode: supports multiple motion modes such as point control, continuous motion, zeroing, and linear interpolation, and is programmable to adapt from simple straight lines to complex multi axis linkage.

Rich peripheral interfaces: can directly connect stepper drivers, limit switches, encoder feedback, support closed-loop position correction, improve positioning accuracy and stability.

Independent axis control design: A single axis independent motion processor that does not occupy the main CPU resources of the PLC, ensuring efficient parallel operation of the main control and motion control in both directions.

Wide temperature industrial grade: working temperature * * -20 ℃~70 ℃ * *, humidity 0%~95%, no condensation, suitable for harsh industrial sites such as high and low temperature, humidity, dust, etc.

Compact standard structure: Complies with the 90-30 series rack specifications, with a compact size and light weight (about 0.2kg), saving cabinet space and supporting dense installation.

Strong anti-interference ability: EMC optimized design, anti electromagnetic interference, anti surge, can operate stably together with frequency converters, servos and other equipment.

High quality hardware selection: military grade PCB, gold-plated contacts, industrial grade chips, anti-oxidation and wear-resistant, with long mechanical and electrical life.

Multiple protection mechanisms: Built in overcurrent, short circuit, overvoltage, and overheating protection to prevent damage to the module and external motors and drivers.

Flexible power supply specifications: Supports 24V DC standard power supply, built-in power filtering and reverse protection, suitable for conventional power sources in industrial sites.

Easy programming debugging: Supports parameterized configuration of GE programming software, supports status monitoring, online modification, fault diagnosis, and reduces debugging difficulty.

Intelligent fault diagnosis: Real time monitoring of pulse output, position deviation, communication status, instant alarm output for abnormalities, and rapid fault location.

International authoritative certification: Through CE, UL, CSA certification, it meets global industrial safety standards and can be exported to various regions around the world.

Full scene coverage: widely used in precision motion control fields such as CNC machine tools, packaging machinery, textile equipment, electronic manufacturing, robots, and automated production lines.

HE693STP104AX, with its core advantages of high speed, precision, stability, and easy integration, has become an ideal choice for achieving precise step motion control in GE 90-30 systems, effectively improving equipment positioning accuracy and production efficiency.
