IC660TSA100电子模块

1.产 品 资 料 介 绍：

IC660TSA100 端子组件

1. 核心定位：为 IC660BBA100 等模拟量模块配套，实现现场信号与模块的可靠对接。
2. 通道配置：提供 4 路模拟输入、2 路模拟输出，支持电压 / 电流型信号。
3. 兼容信号：适配 115VAC、24–48VDC 等工业常用信号类型。
4. 电气隔离：通道间隔离耐压 1500Vrms，抗干扰能力强。
5. 散热性能：额定散热 6W，适配连续运行工况。
6. 工作环境：0–60℃ 运行，-40–85℃ 存储，湿度 5–95% 无冷凝。
7. 安装方式：标准 DIN 导轨安装，适配 Genius 系统机架。
8. 安全认证：通过 CE、UL、CSA 认证，符合工业安全标准。
9. 系统兼容：与 GE 90-30/90-70 PLC 及 Genius 总线无缝适配。
10. 连接特性：集成端子接线，减少现场布线复杂度。
11. 状态指示：配备 GENI OK、COMMS OK 等 LED，便于运行监控。
12. 物理规格：尺寸约 120×80×60mm，重量约 0.65kg，结构紧凑。
13. 低功耗设计：保障长期稳定运行，降低柜内发热。
14. 抗扰设计：工业级器件，抗震动、抗冲击，适配恶劣工况。
15. 应用领域：用于温度、压力、流量等模拟量监测控制，覆盖化工、电力、冶金、制造等行业。

IC660TSA100电子模块     产品英文

IC660TSA100 Terminal Component

IC660TSA100 is an analog terminal assembly of GE Fanuc Genius I/O series, serving as a bridge between field devices and I/O modules, providing stable electrical connections and signal conversion, and adapting to industrial automation systems.

Core positioning: To support analog modules such as IC660BBA100 and achieve reliable integration between on-site signals and modules.

Channel configuration: Provides 4 analog inputs and 2 analog outputs, supporting voltage/current type signals.

Compatible signal: Suitable for commonly used industrial signal types such as 115VAC and 24-48VDC.

Electrical isolation: Channel isolation with a withstand voltage of 1500Vrms and strong anti-interference ability.

Heat dissipation performance: rated heat dissipation of 6W, suitable for continuous operation conditions.

Working environment: Operating at 0-60 ℃, stored at -40-85 ℃, humidity at 5-95% without condensation.

Installation method: Standard DIN rail installation, compatible with Genius system rack.

Safety certification: Passed CE, UL, CSA certification, in compliance with industrial safety standards.

System compatibility: seamlessly compatible with GE 90-30/90-70 PLC and Genius bus.

Connection feature: Integrated terminal wiring, reducing the complexity of on-site wiring.

Status indication: Equipped with GENI OK, COMMS OK and other LEDs for easy operation monitoring.

Physical specifications: dimensions of approximately 120 × 80 × 60mm, weight of approximately 0.65kg, compact structure.

Low power design: ensures long-term stable operation and reduces heating inside the cabinet.

Anti disturbance design: Industrial grade components, resistant to vibration and impact, suitable for harsh working conditions.

Application areas: Used for analog monitoring and control of temperature, pressure, flow rate, etc., covering industries such as chemical, power, metallurgy, and manufacturing.

IC660TSA100 provides a stable connection solution for Genius analog systems with high compatibility, strong isolation, and easy deployment, enhancing signal transmission reliability and system maintainability.
