193X703ADG0继电器板

发布时间:2025-05-09人气:
  • 193X703ADG0继电器板
  • 193X703ADG0继电器板
  • 193X703ADG0继电器板

GE    193X703ADG0继电器板

1.产 品 资 料 介 绍:

中文资料:

GE 193X703ADG01 继电器板 技术说明

产品型号:193X703ADG01
产品名称:继电器板(Relay Board)
制造商:General Electric (GE)
产品系列:193X 控制模块系列
典型用途:工业控制系统中的信号切换、故障联锁、状态转换等控制逻辑执行


一、功能描述

193X703ADG01 是一块专用于工业自动化和驱动系统的多继电器输出控制板,其主要职责是根据控制逻辑切换多路继电器,用于实现:

  • 电气设备的远程启停;

  • 报警信号或联锁逻辑执行;

  • 控制指令的中继输出;

  • 动作状态反馈给上层控制器。


二、技术参数(典型)

项目内容说明
控制输入数字控制信号(来自逻辑板或中央控制器)
输出方式多路继电器干接点输出(常开/常闭)
驱动电压通常为 24VDC 或 ±15VDC(视系统而定)
继电器数量4~8 个(根据子型号具体配置)
安装方式插卡式,使用金手指连接到 193X 背板
板上元器件小型继电器、晶体管、二极管、限流电阻等
尺寸规格标准193X板卡尺寸,带前端抓手

英文资料:

GE 193X703ADG01 Relay Board Technical Description

Product model: 193X703ADG01

Product Name: Relay Board

Manufacturer: General Electric (GE)

Product Series: 193X Control Module Series

Typical application: Control logic execution for signal switching, fault interlocking, state transition, etc. in industrial control systems


1、 Function Description

193X703ADG01 is a multi relay output control board specifically designed for industrial automation and drive systems. Its main responsibility is to switch multiple relays based on control logic to achieve:


Remote start stop of electrical equipment;


Alarm signal or interlock logic execution;


Relay output of control instructions;


Feedback the action status to the upper level controller.


2、 Technical parameters (typical)

Project Content Description

Control input digital control signal (from logic board or central controller)

Output method: Multi channel relay dry contact output (normally open/normally closed)

The driving voltage is usually 24VDC or ± 15VDC (depending on the system)

The number of relays is 4-8 (depending on the specific configuration of the sub model)

Installation method: insert the card and connect it to the 193X backplane with a gold finger

On board components such as small relays, transistors, diodes, current limiting resistors, etc

Size specification standard 193X board size, with front-end gripper

2.产      品      展      示


3.其他产品

 EXM-10A磁盘控制器

 61-0654-22视频模块

 61-0475-20轴控制模块

4.其他英文产品

GE IS200TRLYH1B power converter

ASEA DSQC108 controller backplane

RADISYS 061-05927-0031 adapter module

SM811K01 3BSE018173R1CACR-SR10BB-BF16ES5246-4UA31
SGC 420CACR-SR15SB1AF-Y100EXM-2
SGC 410CACR-TS111Z1SR61-0367-38
SGC 400CACR-TM555Z1SPHSK-0018-60
SGC 120CACR-SR06TZ0SM879-8103-002A
SGC 110CACR-SR05SB1AF61-0881-20
SDO-0824 FC-SDO-08246SC6100-0GB027LA11
SDI-1624 FC-SDI-16246SC6100-0NA216ES5-456-7LA11
