GE 193X706AAG02放大器卡
1.产 品 资 料 介 绍：
中文资料：
GE 193X706AAG02 放大器卡技术资料
产品型号：193X706AAG02
产品名称：放大器卡（Amplifier Card）
制造商：General Electric (GE)
系列：193X 系列工业控制板卡
功能分类：信号放大与增益调节模块（Signal Amplification and Gain Adjustment）
应用领域：工业自动化系统、数据采集、过程控制等
一、产品功能
GE 193X706AAG02 放大器卡是一款用于提高输入信号幅度并提供信号增益的模块。它将输入的微弱信号放大，以便能够被系统下游的其他设备或控制单元所接受。该卡广泛应用于需要信号增益和放大的系统中，如工业自动化控制、传感器信号处理、数据采集系统等。
主要功能：
输入信号放大：将低幅度的模拟信号进行放大，以满足下游设备的输入要求。
增益调节：提供不同的增益选项，适应多种输入信号条件。
信号稳定性：提高信号的稳定性，减少噪声干扰，确保精确控制。
电气隔离：为防止高电压或电气噪声干扰，提供输入与输出的电气隔离。
二、主要技术参数
| 参数项 | 说明描述 |
|---|---|
| 输入信号类型 | 模拟信号，如电压、电流信号，常见为 0-10V、4-20mA 等 |
| 输出信号类型 | 放大后的模拟信号，通常为 0-10V 或其他标准电压输出 |
| 放大增益 | 可调增益，通常提供多个增益设置选项，如 1x、10x、100x 等 |
| 输入输出隔离 | 提供输入与输出之间的电气隔离，防止电气噪声与干扰传递 |
| 电源需求 | ±15V DC 或 24V DC，具体依照系统电源标准 |
| 信号带宽 | 适用于工业应用的宽带信号放大，确保信号准确传递 |
| 工作温度范围 | 通常为 -40°C 到 +85°C，适合各种工业环境使用 |
| 安装方式 | 插卡式，适配 GE 193X 系列控制机架或控制系统框架 |
| 接口类型 | 一般采用端子连接或金属插针接口，用于连接外部传感器和设备 |
| 卡片尺寸 | 标准 GE 插卡式模块尺寸，符合 193X 系列卡片的标准格式 |
英文资料：
GE 193X706AAG02 amplifier card technical data
Product model: 193X706AAG02
Product Name: Amplifier Card
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Function classification: Signal Amplification and Gain Adjustment Module
Application areas: Industrial automation systems, data acquisition, process control, etc
1、 Product Features
The GE 193X706AAG02 amplifier card is a module used to increase input signal amplitude and provide signal gain. It amplifies the weak input signal so that it can be accepted by other downstream devices or control units in the system. This card is widely used in systems that require signal gain and amplification, such as industrial automation control, sensor signal processing, data acquisition systems, etc.
Main functions:
Input signal amplification: Amplify low amplitude analog signals to meet the input requirements of downstream devices.
Gain adjustment: Provides different gain options to adapt to various input signal conditions.
Signal stability: Improve signal stability, reduce noise interference, and ensure precise control.
Electrical isolation: To prevent interference from high voltage or electrical noise, provide electrical isolation between input and output.
2、 Main technical parameters
Parameter item description
The input signal type is analog signal, such as voltage, current signal, commonly 0-10V, 4-20mA, etc
The output signal type is an amplified analog signal, usually ranging from 0-10V or other standard voltage outputs
Amplification gain adjustable gain, usually providing multiple gain setting options such as 1x, 10x, 100x, etc
Input/output isolation provides electrical isolation between input and output, preventing the transmission of electrical noise and interference
Power requirement ± 15V DC or 24V DC, according to the system power standard
Signal bandwidth is suitable for broadband signal amplification in industrial applications, ensuring accurate signal transmission
The working temperature range is usually -40 ° C to+85 ° C, suitable for various industrial environments
Installation method plug-in card, compatible with GE 193X series control rack or control system framework
The interface type generally adopts terminal connection or metal pin interface, which is used to connect external sensors and devices
Card size standard GE plug-in module size, in accordance with the standard format of 193X series cards
2.产 品 展 示
