193X707AAG01电机现场控制卡

GE   193X707AAG01电机现场控制卡

1.产 品 资 料 介 绍：

中文资料：

一、产品功能

GE 193X707AAG01 电机现场控制卡主要用于电机驱动系统中，通过直接控制电机的现场运行情况，调节电机的转速、功率输出、启停状态等。该卡适用于需要实时控制电机或电动机的系统，可以提供高效的电机控制与调节功能，确保电机运行的稳定性与精度。

主要功能：

• 电机控制：实现电机的启停控制、转速调节和电流监测等功能，确保电机在负载变化时平稳运行。

• 现场调节：通过与电机的现场控制接口直接连接，实时调整电机的运行参数。

• 负载监测：监控电机的负载状态，包括电流、电压、温度等，并根据需求调整控制策略。

• 过载保护：在电机过载或异常状态时，自动停机或报警，防止设备损坏。

• 调速功能：支持电机转速的精确调节，适应不同工作状态和负载要求。

二、主要技术参数

三、应用领域

• 工业自动化控制系统：在自动化生产线中应用，控制和调节电机的运行状态，实现自动化驱动。

• 电机驱动与调速系统：在电机驱动系统中提供实时监控与调节电机转速、功率等参数。

• 过程控制系统：适用于需要精确电机控制的工业过程，如化工、冶金、矿山等领域。

• 风机、泵类控制系统：在风机、水泵等需要持续调节电机负载的场合提供现场控制与保护。

• 输送系统：在物料输送系统中提供电机运行的实时控制和状态监控。

英文资料：

1、 Product Features

The GE 193X707AAG01 motor field control card is mainly used in motor drive systems to directly control the on-site operation of the motor, adjust the motor's speed, power output, start stop status, etc. This card is suitable for systems that require real-time control of motors or electric motors, and can provide efficient motor control and regulation functions to ensure the stability and accuracy of motor operation.

Main functions:

Motor control: Implement functions such as start stop control, speed regulation, and current monitoring of the motor to ensure smooth operation during load changes.

On site adjustment: By directly connecting with the on-site control interface of the motor, the operating parameters of the motor can be adjusted in real time.

Load monitoring: Monitor the load status of the motor, including current, voltage, temperature, etc., and adjust the control strategy according to demand.

Overload protection: When the motor is overloaded or in an abnormal state, it automatically stops or alarms to prevent equipment damage.

Speed regulation function: supports precise adjustment of motor speed to adapt to different working conditions and load requirements.

2、 Main technical parameters

Parameter item description

Control methods include analog signal regulation (such as current and voltage) and digital signal input control (such as switch input)

Motor types are suitable for various types of motors such as AC motors, DC motors, synchronous motors, etc

Input signal type control signal (switch signal, analog voltage signal, etc.)

Output signal type motor control signal, such as regulating voltage, current or frequency signal

Power requirement ± 15V DC or 24V DC (depending on actual system power requirements)

Load current monitoring supports current sensor input to monitor motor operating status and load conditions

Environmental temperature range -40 ° C to+85 ° C, suitable for industrial environments

Card size standard GE plug-in card module size, in accordance with the 193X series format

Installation method: plug-in card, compatible with GE 193X series control rack

The communication protocol supports Modbus, Profibus, or other industrial protocols

The working frequency range supports wideband input and adapts to various industrial control requirements

3、 Application Fields

Industrial automation control system: applied in automated production lines to control and regulate the operating status of motors, achieving automated driving.

Motor drive and speed regulation system: Provide real-time monitoring and adjustment of motor speed, power and other parameters in the motor drive system.

Process control system: suitable for industrial processes that require precise motor control, such as chemical, metallurgical, mining and other fields.

Fan and pump control system: Provides on-site control and protection in situations where continuous adjustment of motor load is required for fans, pumps, and other equipment.

Conveyor system: Provides real-time control and status monitoring of motor operation in the material conveying system.

2.产      品      展      示
