1.产 品 资 料 介 绍：
产品特点（15 条）
- 适配系统：专为 KUKA KRC2、KRC2 ED05 机器人控制柜设计，与 MFC3、CI3 等控制模块兼容。
- 通道配置：标配16 路数字输入（DI）+16 路数字输出（DO），共 32 路基础 I/O 通道。
- 输入类型：数字输入为24V DC NPN/PNP 兼容，支持干接点与有源传感器信号接入。
- 输出类型：数字输出为24V DC 晶体管输出，单通道最大驱动电流 0.5A，适配电磁阀、继电器等负载。
- 接口形式：采用标准端子排接线，通道编号清晰，支持快速现场布线与维护。
- 信号隔离：输入 / 输出通道光电隔离，抗干扰能力强，保护控制器免受外部浪涌冲击。
- 状态指示：每路 DI/DO 均配备独立 LED 指示灯，实时显示信号通断，便于快速诊断。
- 电源供电：由控制柜 24V DC 辅助电源供电，无需额外独立电源，简化系统布线。
- 地址配置：支持硬件地址拨码或软件配置，可与其他 I/O 板级联扩展，灵活适配不同 I/O 需求。
- 通信接口：通过 ** 内部总线（如 DSE-IBS）** 与控制器 CPU 通信，信号传输实时性高。
- 防护等级：IP20，仅适用于控制柜内安装，防尘防触，适应工业环境。
- 工作温度：0–55℃，宽温稳定运行，满足车间全天候工作需求。
- 模块化设计：标准 PCI / 槽位安装，支持热插拔（断电操作），更换无需复杂调试。
- EMC 兼容：工业级电磁兼容设计，符合 EN 61000 标准，抗车间强电磁干扰。
- 认证合规：通过 CE、UL 等工业安全认证，适配全球自动化产线应用。
关键参数
- 型号：00-108-036
- 适配系统：KUKA KRC2、KRC2 ED05 控制柜
- 通道数：16 DI + 16 DO（共 32 路）
- 输入电压：24V DC（±10%），NPN/PNP 兼容
- 输出电压：24V DC，单通道最大 0.5A
- 信号隔离：光电隔离
- 安装方式：柜内槽位 / 导轨安装
- 防护等级：IP20
- 工作温度：0–55℃
- 重量：约 0.8kg
应用场景
00-108-036 I/O板单元 英文资料：
00-108-036 is a standard digital I/O interface board dedicated to KUKA KRC2/KRC2 ED05 control cabinet. Its core function is to achieve digital signal interaction between robot controllers and external devices, providing stable 24V DC input/output channels. It is the core hardware for the basic I/O expansion of KRC2 system.
Product features (15 items)
Adaptation System: Designed specifically for KUKA KRC2 and KRC2 ED05 robot control cabinets, compatible with control modules such as MFC3 and CI3.
Channel configuration: Standard configuration includes 16 digital inputs (DI) and 16 digital outputs (DO), totaling 32 basic I/O channels.
Input type: Digital input is 24V DC NPN/PNP compatible, supporting dry contact and active sensor signal access.
Output type: Digital output is 24V DC transistor output, with a maximum single channel driving current of 0.5A, suitable for loads such as solenoid valves and relays.
Interface form: Standard terminal block wiring is adopted, with clear channel numbering, supporting fast on-site wiring and maintenance.
Signal isolation: The input/output channels are optically isolated, with strong anti-interference ability, protecting the controller from external surge impact.
Status indication: Each DI/DO is equipped with an independent LED indicator light, which displays real-time signal on/off for quick diagnosis.
Power supply: Powered by a 24V DC auxiliary power supply from the control cabinet, no additional independent power supply is required, simplifying system wiring.
Address configuration: Supports hardware address dialing or software configuration, can be cascaded and expanded with other I/O boards, and flexibly adapts to different I/O requirements.
Communication interface: Communicate with the controller CPU through an internal bus (such as DSE-IBS), with high real-time signal transmission.
Protection level: IP20, only suitable for installation inside control cabinets, dust-proof and touch proof, suitable for industrial environments.
Working temperature: 0-55 ℃, stable operation over a wide temperature range, meeting the all-weather work requirements of the workshop.
Modular design: Standard PCI/slot installation, supports hot plugging (power-off operation), and replacement does not require complex debugging.
EMC compatibility: Industrial grade electromagnetic compatibility design, compliant with EN 61000 standard, resistant to strong electromagnetic interference in the workshop.
Certification compliance: Through industrial safety certifications such as CE and UL, it is suitable for global automation production line applications.
key parameters
Model: 00-108-036
Adaptation system: KUKA KRC2, KRC2 ED05 control cabinet
Number of channels: 16 DI+16 DO (a total of 32 channels)
Input voltage: 24V DC (± 10%), compatible with NPN/PNP
Output voltage: 24V DC, maximum 0.5A per channel
Signal isolation: photoelectric isolation
Installation method: Cabinet slot/rail installation
Protection level: IP20
Working temperature: 0-55 ℃
Weight: Approximately 0.8kg
00-108-036 I/O板单元 产品展示
