00-109-040接口板

00-109-040接口板

1.产 品 资 料 介 绍：

1. 产品定位：KVGA 2.0 视频接口板，备件号 00-109-040，适配 KRC2、KRC2 ED05 控制柜，替代早期 KVGA 1.0 版本。
2. 核心功能：处理工控机图形数据，输出视频信号至示教器与外接 VGA 显示器，实现系统界面可视化。
3. 接口配置：双 KCP 示教器接口 + 1 路标准 VGA 接口，支持示教器与外接显示器并行显示。
4. 信号标准：兼容 VGA 视频标准，分辨率最高支持 1024×768，刷新率 60Hz，画面清晰稳定。
5. 通信连接：通过内部总线与 MFC3 处理器模块（00-109-026）直连，信号传输实时无延迟。
6. 供电规格：24V DC 供电，电压范围 18–30V DC，由控制柜辅助电源供电，无需额外电源。
7. 硬件设计：工业级 PCB，金属屏蔽外壳，抗电磁干扰，适配车间复杂电磁环境。
8. 状态指示：板载 LED 指示灯，实时显示供电、视频输出、通信状态，便于快速诊断。
9. 即插即用：原装位设计，接口与 KVGA 2.0 标准一致，更换无需改造，维护便捷。
10. 散热设计：无风扇被动散热，工作温度 - 10℃～+55℃，支持 24 小时连续运行。
11. 保护功能：内置过压、过流、短路保护，硬件看门狗，故障自动复位。
12. EMC 合规：通过 EN 61000-6-2/6-4 电磁兼容认证，抗干扰能力强。
13. 软件兼容：支持 KSS 5.x/6.x 系统，兼容示教器操作、程序编辑与系统监控。
14. 应用场景：用于机器人编程调试、产线监控、故障诊断，适配库卡 KR 16、KR 30 等中负载机器人。
15. 合规认证：通过 CE、TÜV 认证，符合欧盟工业设备安全规范。
16. 兼容性：兼容库卡 KCP2、KCP2.0 示教器，支持外接标准 VGA 工业显示器。

00-109-040接口板 英文资料：

00-109-040 is a KVGA 2.0 video interface board specifically designed for KUKA KRC2/KRC2 ED05 control cabinet. Its core function is to connect an industrial computer with a teaching pendant (KCP) and an external display, enabling video signal output and interactive control.

Product positioning: KVGA 2.0 video interface board, spare part number 00-109-040, compatible with KRC2 and KRC2 ED05 control cabinets, replacing the early KVGA 1.0 version.

Core function: Process graphics data from industrial control computers, output video signals to teaching devices and external VGA displays, and achieve system interface visualization.

Interface configuration: Dual KCP teaching pendant interface+1 standard VGA interface, supporting parallel display of teaching pendant and external monitor.

Signal standard: Compatible with VGA video standard, with a maximum resolution of 1024 × 768, a refresh rate of 60Hz, and clear and stable images.

Communication connection: Directly connected to the MFC3 processor module (00-109-026) through an internal bus, with real-time signal transmission without delay.

Power supply specification: 24V DC power supply, voltage range 18-30V DC, powered by auxiliary power supply of control cabinet, no additional power supply required.

Hardware design: Industrial grade PCB, metal shielding shell, anti electromagnetic interference, suitable for complex electromagnetic environments in workshops.

Status indication: Onboard LED indicator lights display real-time power supply, video output, and communication status for quick diagnosis.

Plug and play: original design, interface consistent with KVGA 2.0 standard, no need for modification for replacement, easy maintenance.

Heat dissipation design: fanless passive heat dissipation, working temperature -10 ℃~+55 ℃, supporting 24-hour continuous operation.

Protection function: Built in overvoltage, overcurrent, and short-circuit protection, hardware watchdog, automatic fault reset.

EMC compliance: Passed EN 61000-6-2/6-4 electromagnetic compatibility certification, with strong anti-interference ability.

Software compatibility: Supports KSS 5. x/6. x systems, compatible with teaching pendant operation, program editing, and system monitoring.

Application scenarios: Used for robot programming and debugging, production line monitoring, fault diagnosis, and adaptation to medium load robots such as KR 16 and KR 30.

Compliance certification: Passed CE and T Ü V certifications, in compliance with EU industrial equipment safety regulations.

Compatibility: Compatible with KCP2 and KCP2.0 teaching devices, supporting external standard VGA industrial displays.

00-109-040接口板  产品展示
