1.产 品 资 料 介 绍：

核心技术参数

性能特点

• 低功耗高性能：PowerPC 750 处理器在 400 MHz 下性能稳定，功耗低，适合长时间运行。
• 高可扩展性：双 PMC 槽可灵活扩展 CAN、光纤、高速数据采集等功能卡。
• 可靠性设计：支持热插拔、ECC 内存及看门狗定时器，增强系统稳定性。
• 多操作系统兼容：支持 VxWorks、Linux 等，便于不同应用场景开发。

应用场景

• 工业自动化控制系统
• 通信基站与网络设备
• 测试测量与数据采集系统
• 军事与航空航天嵌入式平台

Motorola POWERCORE CPCI-6750单板计算机 英文资料：

Motorola POWERCORE CPCI-6750 is a high-performance single board computer (SBC) based on the CompactPCI (CPCI) architecture, suitable for embedded systems such as industrial control, communication equipment, testing and measurement. It uses a PowerPC 750 processor, with a maximum clock speed of 400 MHz, onboard 16 MB to 256 MB SDRAM, 8 MB user Flash, 1 MB L2 cache, and features dual RS-232, 10/100 Base TX Ethernet, PMC expansion slots, and programmable watchdog. CPCI-6750 complies with PICMG specifications, supports hot plugging, and facilitates system expansion and maintenance.

Core technical parameters

Project specifications

Processor PowerPC 750300 MHz/400 MHz

Memory 16 MB -256 MB SDRAM (ECC optional)

Store 8 MB of user Flash and 512 KB of Boot Flash

Cache 1 MB L2 cache

Network 10/100 Base TX Ethernet

Serial port 2-channel RS-232

Two PMC (PCI Mezzanine Card) expansion slots

Real time clock onboard RTC

Watchdog programmable

The power supply and mechanical components comply with PICMG 2.0 R3.0 and support hot swapping

The operating system supports VxWorks, Linux, etc

Performance Characteristics

Low power consumption and high performance: The PowerPC 750 processor has stable performance at 400MHz, low power consumption, and is suitable for long-term operation.

High scalability: The dual PMC slots can flexibly expand functional cards such as CAN, fiber optic, and high-speed data acquisition.

Reliability design: Supports hot swapping, ECC memory, and watchdog timer to enhance system stability.

Multi operating system compatibility: Supports VxWorks, Linux, etc., making it easy to develop different application scenarios.

Application scenarios

industrial automation control system

Communication base stations and network equipment

Test measurement and data acquisition system

Military and Aerospace Embedded Platform

 Motorola POWERCORE CPCI-6750单板计算机 产      品      展      示
